CHAM-DIM-DMX - Master LED Universal 4 Channel

The CHAM-DIM-DMX - Master LED Universal 4 Channel  is an interface designed to decode DMX-512 signals. Designed
for use with 12-24V DC Constant Voltage LED lighting products the CHAM-DIM-DMX - Master LED Universal 4 Channel offers seamless integration between automation systems and/or lighting desk consoles and luminaires.

Accepts standard DMX-512 signal generated from any automation system or lighting control console. Featuring up to 4CH of dimming, allowing control over RGB, RGBW or single colour LED lighting products.

Products To Be Used In Conjunction:

Power Supply: 12V/24V DC Constant Voltage LED Driver

Expandable Data Signal Repeater: CHAM-DR-4C


Variant: 20129 - LED Universal 4 Channel RGB/RGBW And Single Colour DMX Interface (previously known as CHAM-20).

• Type of Controller: RGBW 4 Channel Controller
• Method of Control: DMX-512*
• Method of Dimming: PWM (Pulse width modulation)
• Housing Colour: Black plastic colour housing
• Digital Display: Yes
• Multi-Channel Operation: Yes**
• Expandable signal: Yes***
• Requires: 12-24V DC Constant Voltage LED Driver****

Specifications:

• Input Voltage (VDC): 12-24V DC
• Output Voltage (VDC): 12-24V DC
• Output Current (A): 4x8A
• Output Wattage (W): 12V DC - 96W per channel (x4)
• Output Wattage (W): 24V DC - 192W per channel (x4)

Dimensions:

• Housing size (mm): (L) 168mm x (W) 58mm x (H) 28mm
