Oren 24W LED Surface Mounted Downlight Dimmable

The Oren CTC918 is a 180 mm surface-mounted LED downlight in black or white sand — 24 W giving 2,060 lm, switchable 2700 K / 3000 K / 4000 K, CRI above 92, TRIAC dimmable, IP54.

2,060 lumens — the one that lights a room on its own

The largest Oren, and at this output it stops being a downlight in a run and becomes a single ceiling light: a bathroom, a laundry, a hallway, an entry porch, a small bedroom, lit properly from one fitting. On a concrete or shallow ceiling where you cannot install a grid of recessed lights, that is often the only clean answer.

The dimensions were published back to front

Our table gave “Width 90 mm, Height 180 mm” — which would be a tube hanging 180 mm below the ceiling. It is 180 mm across and 90 mm deep. The 90 mm is identical on all three sizes while the other varies 120 / 150 / 180, exactly matching the model numbers CTC912, CTC915, CTC918. Confirm with us before you order — at this size the difference between 90 and 180 mm across changes how the fitting reads on a ceiling entirely.

CRI above 92, at 86 lumens per watt

Most downlights here record CRI 80; the Oren records above 92, which shows on skin, timber, food and fabric. Note that this largest size is the least efficient of the three — 86 lm/W against the 120 mm's 96 — which is normal: more power in a body that is wider but no deeper runs warmer, and heat costs output.

36-degree beam from a 180 mm body

A focused beam from a fitting that sits 90 mm below the ceiling. In a room with a normal ceiling that gives a well-defined pool with a clean edge — good over a shower, a bench or an entry mat, less good if you want an even wash across a whole room. If a wash is what you want, two of the 120 mm will do it better than one of these.

Where it works

• Bathrooms, laundries, entries and hallways — as the only light.
• Concrete and shallow ceilings — no cutout, no void.
• Porches and covered alfresco.
• ⚠ A defined pool, not an even wash — two smaller ones wash better.
• ⚠ IP54 — covered outdoor positions, not exposed.

Specifying it

180 mm diameter, 90 mm deep — our table had these reversed — at 0.6 kg, in aluminium, sand finish. Integrated 24 W COB LED giving 2,060 lm, included, with switchable 2700 K / 3000 K / 4000 K, CRI >92, 36° beam, TRIAC dimmable. 240 V, Class I — earth required, IP54 — splash-rated; covered positions, surface-mounted — no cutout required. Warranty is three years, as a replacement warranty.

Supplied and supported by Lights For You.

Download Datasheet (PDF)
