Domus PLEX-ULTRA 10W P/M COB Strip 24V CRI90 IP67 560LED/M 50M Pack

The Domus PLEX-ULTRA IP67 is a 24 V COB LED strip — 10 W per metre, 560 LEDs per metre, CRI ≥90, IP67, 50 m pack, at 650 / 669 / 688 lm per metre.

⭐⭐ Fifty metres, sealed, dotless, five openings

• ⭐ At a 26 m two-end limit, fifty metres is two runs, one cut and four terminations — five openings in the silicon coating.
• ⭐ The same fifty metres of sealed PLEX-COB is five runs, four cuts and twenty terminations — twenty-nine.

• ⭐⭐ SO IF THE STRIP WILL BE SEEN, THIS IS THE BEST LONG SEALED RUN AVAILABLE. ⭐ It matches the SMD strip's opening count and driver count while staying dotless, and it beats sealed PLEX-COB by twenty-four openings.
• ⭐ Every opening matters because none of the range's connectors is rated above IP20 — ⭐ each has to end up somewhere dry, and five is a solvable layout where twenty-nine is not.

⭐ The coating costs 15%, which is now a measured constant

⭐ 650 / 669 / 688 lm per metre against the IP54 version's 770 / 790 / 810. ⭐⭐ Across the programme we have measured that penalty on 23 pairs in four product families — COB and SMD, whites and saturated colours — mean 15.4% with very little spread. ⭐ It is the silicon absorbing light. ⭐ Over fifty metres it is the difference between about 40,000 lumens and about 34,000. ⭐ Take IP67 where water arrives with force; take IP54 and keep the 15% where it does not.

⭐ 500 W and about 34,000 lumens

⭐ Two drivers of about 270 W each. ⚠ On a wet-area job the dry, ventilated, accessible driver location is usually harder to find than the strip position — ⭐ so needing two rather than five is worth more here than on a dry run. ⭐ 500 W wants its own circuit.

⛔⛔ Fifty metres of mandatory profile — and it must suit the exposure

⭐ The sheet requires an aluminium heat sink in capitals and voids the warranty without it. ⭐ On the IP67 version the coating is also a thermal blanket, so the aluminium is the only path heat has out — ⭐ the requirement is least marginal here. ⚠ And if any of the run is external, the profile has to survive UV, thermal cycling and possibly salt. ⛔ None of the catalogue's 47 profiles states its outdoor suitability.

✅ What is published

⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works

• ⭐⭐ Long visible wet-area lines — ⭐ the best sealed dotless run available.
• ⭐ Pool halls, spas, commercial kitchens.
• ⭐ Covered external colonnades and soffits.
• ⛔ Never without an exposure-suitable profile.
• ⚠ Not for a bathroom — ⭐ IP54 gives 15% more light.

Specifying it

COB LED strip, IP67 silicon coated, 50 m pack. 10 W per metre at 24 V DC, 500 W total, ≈34,000 lm. 560 LEDs per metre, dotless. CRI ≥90. 180° beam. 25 mm cutting increment. Continuous run 13 m one-end, 26 m two-end. Aluminium heat sink mandatory. 3-year warranty. ⭐⭐ IF THE STRIP WILL BE SEEN, THIS IS THE BEST LONG SEALED RUN AVAILABLE. Fifty metres is two runs, two drivers and FIVE openings in the coating — matching the SMD strip's counts while staying dotless, and beating sealed PLEX-COB by twenty-four openings. Every opening matters because no connector in the range is rated above IP20, so each has to end up somewhere dry: five is a solvable layout, twenty-nine is not.

Supplied and supported by Lights For You.
