Domus Lighting LED Strip Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Domus Lighting LED Strip Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 24202

Domus PLEX-SMD 9W P/M Strip 24V CRI90 IP67 120LED/M 50M Pack

IP67 – waterproof to 1m depth
IP67 – waterproof to 1m depth
$2,109.95
$2,109.95
Product Description
Product Description
x

The Domus PLEX-SMD-9 IP67 is a 24 V SMD LED strip — 9 W per metre, 120 LEDs per metre, CRI ≥90, IP67, 50 m pack, at 650 / 687 / 725 lm per metre.

⭐⭐ Fifty metres, sealed, in two runs
  • ⭐ At a 40 m two-end limit, fifty metres is two runs, one cut and two drivers. ⭐ Five openings in the silicon coating in total.
  • ⭐ The same fifty metres of sealed PLEX-COB is five runs, four cuts and twenty terminations — twenty-nine openings.
50 m of IP67 Runs Drivers ⭐ Seal openings
⭐ PLEX-SMD-9 — this ⭐ 2 ⭐ 2 ⭐ 5
PLEX-ULTRA IP67 2 2 5
⚠ PLEX-COB IP67 ⚠ 5 ⚠ 5 ⚠ 29
  • ⭐⭐ TWENTY-FOUR FEWER PLACES THE WATERPROOFING CAN FAIL. ⭐ On a long external or wet-area run, that is the finding that should decide the order — ⚠ and it appears on no page.
  • ⭐ NOTE THAT PLEX-ULTRA MATCHES IT AT THIS LENGTH, AND IS DOTLESS. ⭐ If the strip will be seen, ULTRA is the better answer for the same opening count. ⭐ This one wins on output per metre and on cost.
⭐ 450 W and about 36,000 lumens

⭐ Two drivers of about 270 W each. ⚠ Those are large units needing ventilated, accessible, dry homes — ⭐ and on a wet-area job the dry accessible location is usually harder to find than the strip position. ⭐ Two of them is a solvable problem; five would not be. ⭐ 450 W also wants its own circuit.

⭐ Where fifty metres of sealed strip actually goes

⭐ Commercial kitchens and washdown areas, external soffits and colonnades, pool halls, car park perimeters, covered walkways. ⭐ These are runs measured in tens of metres where the lighting is concealed and the environment is wet — ⭐ exactly the case this product suits and the dotless strips do not. ⚠ If any part of the run is at eye level and visible, consider mixing: ULTRA where it is seen, this where it is not.

⛔⛔ Fifty metres of mandatory profile

⭐ The sheet requires an aluminium heat sink in capitals and voids the warranty without it. ⭐ Fifty metres of strip means fifty metres of extrusion, in jointed lengths, and on an external run it has to survive UV, thermal cycling and — near the coast — salt. ⛔ None of the catalogue's 47 profiles states its outdoor suitability. ⭐ This is the detail most likely to be got wrong on a long external order; ask us first.

⭐ One roll is one batch

⭐ Fifty metres is a single production run, so both lengths match. ⭐ Beyond fifty metres, ask us for consecutive rolls from one batch — free to request, impossible afterwards.

✅ What is published
Specification Value
⭐⭐ 50 m sealed is ⭐ 2 runs · 2 drivers · 5 seal openings
⚠ The same in PLEX-COB IP67 ⚠ 5 runs · 5 drivers · 29 openings
Load 9 W per metre — ⭐ 450 W total
⭐ Output ⭐ 650 / 687 / 725 lm per metre — ⭐ ≈36,000 lm total
⭐ Drivers ⭐ 2 at ≈270 W — ⚠ large, ⭐ but two locations
⭐ Continuous run 20 m one-end · ⭐ 40 m two-end
⭐ Cutting increment ⭐ 25 mm
⛔ LED density ⛔ 120 per metre — ⚠ not dotless
⛔ Aluminium heat sink ⛔ MANDATORY — ⚠ outdoor-suitable if external
⭐ Batch ⭐ One roll is one batch
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐⭐ Long concealed wet-area runs — ⭐ 5 openings, not 29.
  • ⭐ External soffits, colonnades, covered walkways.
  • ⭐ Commercial kitchens and washdown areas.
  • ⛔ Not where visible — ⭐ PLEX-ULTRA matches the openings and is dotless.
  • ⛔ Never without an outdoor-suitable profile.
Specifying it

SMD LED strip, IP67 silicon coated, 50 m pack. 9 W per metre at 24 V DC, 450 W total, ≈36,000 lm. 120 LEDs per metre. CRI ≥90. 120° beam. 25 mm cutting increment. Continuous run 20 m one-end, 40 m two-end. Aluminium heat sink mandatory. 3-year warranty. ⭐⭐ FIFTY METRES SEALED IN TWO RUNS, WITH FIVE OPENINGS IN THE COATING WHERE PLEX-COB WOULD NEED TWENTY-NINE — twenty-four fewer places the waterproofing can fail. On a long external or wet-area run that is the finding that should decide the order, and it appears on no page. ⭐ NOTE PLEX-ULTRA MATCHES THE OPENING COUNT AT THIS LENGTH AND IS DOTLESS, so if the strip will be seen, ULTRA is the better answer; this one wins on output per metre and on cost.

Supplied and supported by Lights For You.

Questions
How many runs is fifty metres?

Two, with one cut and two drivers — at a 40 metre two-end limit. That is five openings in the silicon coating in total, where the same fifty metres of sealed PLEX-COB is five runs, four cuts and twenty terminations: twenty-nine openings.

Why is the opening count the thing to look at?

Because on a sealed strip each opening is a place the waterproofing can fail, and none of the range's connectors is rated above IP20 — so every one has to end up somewhere dry. On a long external or wet-area run, twenty-four fewer of them is the finding that should decide the order. It appears on no page.

Is there a better option?

PLEX-ULTRA IP67 matches the opening count at this length and is dotless, so if the strip will be seen, ULTRA is the better answer. This one wins on output per metre and on cost. If part of the run is visible and part is not, mixing them is sensible.

What is the load?

450 watts across fifty metres, on two drivers of about 270W each. Those are large units needing ventilated, accessible, dry homes — and on a wet-area job the dry accessible location is usually harder to find than the strip position. Two of them is a solvable problem; five would not be. 450W also wants its own circuit.

Where does fifty metres of sealed strip actually go?

Commercial kitchens and washdown areas, external soffits and colonnades, pool halls, car park perimeters, covered walkways. Runs measured in tens of metres where the lighting is concealed and the environment is wet — exactly the case this suits and the dotless strips do not.

What about the profile?

Fifty metres of it, mandatory. The sheet voids the warranty without an aluminium heat sink, and on an external run the profile also has to survive UV, thermal cycling and — near the coast — salt. None of the catalogue's 47 profiles states its outdoor suitability. This is the detail most likely to be got wrong on a long external order.

Will the two runs match?

Yes — fifty metres is a single production run, so both lengths come from the same batch. Beyond fifty metres, ask us for consecutive rolls from one batch; free to request and impossible afterwards.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsPLEX-SMD-9 IP67 50M Pack — 24202 3000K, 24203 4000K, 24204 5000K
⭐⭐ 50 m SEALED = 2 RUNS · 2 DRIVERS · 5 OPENINGS⚠ PLEX-COB IP67: 5 runs · 5 drivers · 29 openings
⭐⭐ TWENTY-FOUR FEWER FAILURE POINTS⚠ And it appears on no page
⭐ Which matters because⛔ No connector above IP20 — ⭐ every opening must end up dry
⭐ PLEX-ULTRA IP67 matches the count⭐ And is DOTLESS — ⭐ better if the strip is seen
⭐ This wins on⭐ Output per metre and cost
⭐ Load and output⭐ 450 W → ⭐ ≈36,000 lm
⭐ Drivers⭐ 2 at ≈270 W — ⚠ large, ⭐ but two locations not five
⭐ Where it goesCommercial kitchens · external soffits · pool halls · covered walkways
⛔ 50 m of mandatory profile⚠ UV, thermal cycling and salt if external
⛔ None of the 47 profiles states outdoor suitability⭐ The detail most likely to be got wrong

Variant specifications

50 m IP67RunsDrivers⭐ Openings
⭐ PLEX-SMD-9⭐ 2⭐ 2⭐ 5
⭐ PLEX-ULTRA225
⚠ PLEX-COB⚠ 5⚠ 5⚠ 29
