Domus Lighting
SKU: 24151

Domus PLEX-Rgb+tune/Wht 21W P/M COB Strip 24V IP54 840LED/M 1m

IP54 – dust and splashproof
IP54 – dust and splashproof
$60.95
$60.95
Product Description
Product Description
x

The Domus PLEX-RGBTW is a 24 V COB LED strip — 21 W per metre, 840 LEDs per metre, IP54, 1 m, combining RGB colour with tuneable white.

⛔⛔ The datasheet attached to this listing is not for this product
  • ⭐ We compared the attached sheet against the verified sheet for the IP67 version of the same strip. ⭐ Seven specifications disagree, and not marginally:
Specification ⛔ The attached sheet ⭐ This product
LED type ⛔ 5050 SMD ⭐ COB
LEDs per metre ⛔ 60 ⭐ 840
Wattage per metre ⛔ 19.2 W ⭐ 21 W
IP rating ⛔ IP20 ⭐ IP54
CRI ⛔ 80 ⭐ ≥90
Beam angle ⛔ 120° ⭐ 180°
Cutting increment ⛔ 100 mm ⭐ 35.7 mm
  • ⭐ 60 LEDs per metre against 840 is a factor of fourteen. ⭐ IP20 against IP54 is the difference between a strip that must stay dry and one rated for wet areas. ⭐ These are two different products.
  • ⭐ SO WE HAVE NOT USED IT. ⭐ Every figure on this page comes from the verified sheet for the IP67 version of the same strip, with the IP rating taken from this product's own title and record.
  • ⚠ One consequence: we cannot give you per-channel lumens for the IP54 version specifically. ⭐ The IP67 figures are Red 110, Green 260, Blue 55 and white 285–325 lm per metre, ⭐ and elsewhere in this range the IP54 version runs about 15% BRIGHTER than IP67 because there is no silicon coating absorbing light. ⚠ We would expect the same here, but we have not measured it and we are not going to state it as published.
⭐ What we can say with confidence

⭐ The title, the product record and the family description agree on the important things: ⭐ 840 LEDs per metre, so genuinely dotless; 21 W per metre, the highest load in the strip range; 24 V DC; IP54, meaning indoor including wet areas; and RGB plus a separate tuneable white channel. ⭐ The run limit is 5 m from one end and 10 m from two.

⭐ The separate white channel is the point of the product

⭐ A plain RGB strip makes white by mixing three channels, and that white has spikes and gaps — skin and timber look wrong under it. ⭐ This carries a dedicated white channel that is tuneable in temperature and renders at CRI ≥90 on the verified sibling. ⭐ So one installation gives you proper everyday white and saturated colour when it is wanted, rather than a compromise at both.

⚠ And plan for blue being quiet

⭐ On the verified sibling, green measures 260 lm per metre and blue 55 — ⭐ a factor of 4.7. ⭐ That is the eye's own sensitivity curve rather than a fault, and it applies to every RGB product. ⚠ A blue-dominant scheme will read far quieter than the green or white ones. ⭐ Worth knowing before the strip is installed rather than after.

✅ What is published
Specification Value
⛔ Attached datasheet ⛔ Is for a DIFFERENT product — 7 specs disagree
⭐ Source used here ⭐ The verified sheet for the IP67 sibling
⭐ LED density ⭐ 840 per metre — ⭐ dotless
Load ⭐ 21 W per metre — ⭐ the highest in the range
IP rating IP54 — ⭐ indoor including wet areas
⭐ Continuous run 5 m one-end · ⭐ 10 m two-end
⭐ White channel ⭐ Separate, tuneable, ⭐ CRI ≥90 on the sibling
⚠ Per-channel lumens ⚠ Not available for IP54 — ⭐ ask us
⛔ Controller ⛔ REQUIRED as well as a driver
⛔ Aluminium heat sink ⛔ MANDATORY — VOIDS THE WARRANTY
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Indoor spaces wanting white daily and colour occasionally.
  • ⭐ Kitchens, bars, pelmets, living spaces.
  • ⭐ Where a dotless line matters — ⭐ 840 LEDs/m.
  • ⚠ Not outdoors — ⭐ IP54 is indoor wet areas; ⭐ take the IP67.
  • ⛔ Not without a controller.
Specifying it

RGBTW COB LED strip, IP54, 1 m. 21 W per metre at 24 V DC. 840 LEDs per metre, dotless. Separate tuneable white channel. 180° beam. Continuous run 5 m one-end, 10 m two-end. Driver AND controller required. Aluminium heat sink mandatory. 3-year warranty. ⛔⛔ THE DATASHEET ATTACHED TO THIS LISTING IS FOR A DIFFERENT PRODUCT — seven specifications disagree, including 60 LEDs per metre against 840 (a factor of fourteen) and IP20 against IP54. WE HAVE NOT USED IT. Every figure here comes from the verified sheet for the IP67 version of the same strip, and the IP rating from this product's own title and record. ⚠ One consequence: per-channel lumens for the IP54 version specifically are not available — ask us and we will get them from Domus.

Supplied and supported by Lights For You.

Questions
Is the datasheet on this listing correct?

No. We compared it against the verified sheet for the IP67 version of the same strip and seven specifications disagree — 5050 SMD against COB, 60 LEDs per metre against 840, 19.2W against 21W, IP20 against IP54, CRI80 against ≥90, 120 degrees against 180, and a 100mm cutting increment against 35.7mm. These are two different products.

So where do your figures come from?

The verified sheet for the IP67 version of the same strip, with the IP rating taken from this product's own title and record. We have not used the attached sheet for anything.

What can you not tell me?

Per-channel lumens for the IP54 version specifically. The IP67 figures are Red 110, Green 260, Blue 55 and white 285 to 325 lumens per metre, and elsewhere in this range the IP54 version runs about 15% brighter than IP67 because there is no silicon coating absorbing light. We would expect the same here — but we have not measured it and we will not state it as published. Ask us and we will get it from Domus.

What are you confident about?

840 LEDs per metre so genuinely dotless, 21W per metre which is the highest load in the strip range, 24V DC, IP54 meaning indoor including wet areas, and RGB plus a separate tuneable white channel. The run limit is 5 metres from one end and 10 from two. The title, the product record and the family description all agree on these.

Why does the separate white channel matter?

Because a plain RGB strip makes white by mixing three channels, and that white has spikes and gaps — skin and timber look wrong under it. This carries a dedicated white channel, tuneable in temperature and rendering at CRI ≥90 on the verified sibling. One installation gives proper everyday white and saturated colour when wanted, rather than a compromise at both.

Anything to plan for with colour?

Blue will be quiet. On the verified sibling green measures 260 lumens per metre and blue 55, a factor of 4.7 — the eye's own sensitivity curve rather than a fault, and it applies to every RGB product. A blue-dominant scheme reads far quieter than the green or white ones. Worth knowing before the strip is installed rather than after.

What else do I need?

A 24V DC constant-voltage driver and a controller to address the four channels, plus an aluminium profile — the heat-sink requirement voids the warranty if omitted. None of the three is included and none is mentioned on the page.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUPLEX-RGBTW IP54 1m — 24151
⛔⛔ THE ATTACHED DATASHEET IS FOR A DIFFERENT PRODUCT⭐ Seven specifications disagree
⛔ LEDs per metre⛔ Sheet says 60 · ⭐ product is 840 — ⭐ a factor of FOURTEEN
⛔ IP rating⛔ Sheet says IP20 · ⭐ product is IP54
⛔ Also disagreeingLED type · wattage · CRI · beam angle · cutting increment
⭐ SO WE HAVE NOT USED IT⭐ Figures here come from the VERIFIED IP67 sibling sheet
⚠ One consequence⚠ No per-channel lumens for IP54 specifically — ⭐ ask us
⭐ What we are confident about⭐ 840 LEDs/m dotless · ⭐ 21 W/m · IP54 · ⭐ separate white channel
⭐ Continuous run5 m one-end · ⭐ 10 m two-end
⚠ Plan for blue being quiet⭐ Green 260 lm/m vs blue 55 on the sibling — ⭐ a factor of 4.7
⛔ Driver AND controller AND profile⛔ None included, ⚠ none mentioned on the page

Variant specifications

Spec⛔ Attached sheet⭐ This product
LEDs/m⛔ 60⭐ 840
IP⛔ IP20⭐ IP54
LED type⛔ 5050 SMD⭐ COB
CRI⛔ 80⭐ ≥90
