Domus Lighting LED Strip Domus PLEX RGB 14W P/M COB Strip 24V IP54 840LED/M 50M Pack
Domus Lighting LED Strip Domus PLEX RGB 14W P/M COB Strip 24V IP54 840LED/M 50M Pack
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 24157

Domus PLEX RGB 14W P/M COB Strip 24V IP54 840LED/M 50M Pack

IP54 – dust and splashproof
IP54 – dust and splashproof
$2,168.95
$2,168.95
Product Description
Product Description
x

The Domus PLEX-RGB COB is a 24 V RGB COB LED strip — 14 W per metre, 840 LEDs per metre, IP54, 50 m pack.

⭐⭐ It looks better than flex and runs a quarter as far
  • ⭐ Domus publishes the run limit outright: 5 m with a single tail and driver, 10 m with a tail and driver at each end.
  • ⭐ Set that beside the PLEO neon flex, which publishes 20 m from one feed and 40 m from both. ⭐ The comparison is not close:
⭐ PLEX COB (this) PLEO flex 7.2 W
Load per metre 14 W 7.2 W
⭐ Run, one feed ⭐ 5 m ⭐ 20 m
Total watts at that run 70 W 144 W
⭐ LED density ⭐ 840 / m — dotless 140 / m
Cut increment ⭐ 25 mm 50 mm
  • ⭐ The COB strip carries HALF the total watts over a QUARTER of the distance. ⭐ So it is not simply a current limit — ⭐ if it were, 70 W would carry further than 144 W, not a quarter as far. ⚠ The COB strip's conductors must be lighter than the flex's. ⭐ Offered as reasoning from the two published figures, not as a Domus statement.
  • ⭐ THE PRACTICAL CONSEQUENCE, and it changes layouts: a 12 m kitchen run is ONE PLEO flex and one driver, or THREE COB sections with three feeds. ⭐ That is three driver locations to find, three cable routes, and three things to fail.
  • ⭐ So the choice is genuine: COB for a short run seen close, where dotless matters; ⭐ flex for a long run where reach matters more than the last degree of smoothness.
⭐ A 50 m pack — and what it is really for

⭐ At a 5 m single-feed limit, a 50 m pack is not one run — ⭐ it is ten of them, or five fed from both ends. ⭐ So this format suits a project rather than a room: a fitout with the same detail repeated through many spaces, bought once and cut on site. ⚠ It also means ten drivers, or five — ⭐ and that is the cost line people miss when comparing COB against a longer-reaching product. ⭐ Tell us the total metreage AND the number of separate runs; the second figure sets the driver count.

⭐ 25 mm cutting increments — half the flex's

⭐ At 840 LEDs per metre, one LED sits every 1.19 mm, and 25 mm holds 21 of them. ⭐ So a cut segment is a block of 21 LEDs, and 25 mm is where that block ends. ⭐ A 25 mm increment is finer than the PLEO flex's 50 mm — ⭐ so your run rounds to half the error. ⭐ On lettering or a detail butting into a return, that is a real advantage.

✅ What is published
Specification Value
Format ⭐ 50 m pack — ⭐ ten 5 m runs, or five fed both ends
⭐ Maximum run ⭐ 5 m one feed · 10 m both ends
Load 14 W per metre at 24 V DC — ⭐ 70 W per 5 m run
⭐ LED density ⭐ 840 per metre — dotless
⭐ Cut increment ⭐ 25 mm — ⭐ a block of 21 LEDs
Colour / IP RGB · IP54 — ⭐ an IP67 version exists
Controller ⭐ CHAM-BT-RF-5C, 5 channel
Dimmable ✅ Yes
⛔ Driver count for a 50 m pack ⛔ Not stated — ⭐ it is 10, or 5 if fed both ends
⛔ Lumen output · warranty ⛔ Not published
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Fitouts repeating one detail across many rooms — ⭐ buy once, cut on site.
  • ⭐ Short runs seen close — ⭐ where dotless matters.
  • Kitchens, bathrooms, bars, restaurants — ⭐ IP54.
  • ⛔ Not a single long run — ⚠ 5 m is the limit.
  • ⚠ Not costed without counting the drivers.
Specifying it

RGB COB LED strip, 50 m pack. 14 W per metre at 24 V DC. 840 LEDs per metre, dotless. IP54. 25 mm cutting increments. Maximum run 5 m with a single tail and driver, 10 m fed both ends. Dimmable. CHAM-BT-RF-5C controller. ⭐⭐ IT LOOKS BETTER THAN FLEX AND RUNS A QUARTER AS FAR — 5 m from one feed against the PLEO flex's 20 m, while carrying HALF the total watts. ⭐ So it is not simply a current limit; the COB strip's conductors must be lighter. ⭐ THE CONSEQUENCE CHANGES LAYOUTS: a 12 m kitchen run is ONE flex and one driver, or THREE COB sections with three feeds — three driver locations, three cable routes, three things to fail. ⭐ A 50 m pack is ten runs, not one.

Supplied and supported by Lights For You.

Questions
How long a run can I have?

5 metres with a single tail and driver, or 10 metres with a tail and driver at each end. Domus publishes both figures outright, which is unusual and genuinely useful.

How does that compare with the PLEO neon flex?

It is not close. The flex reaches 20 metres from one feed and 40 from both; this reaches 5 and 10. And the comparison is stranger than it first looks: the COB strip carries half the total watts over a quarter of the distance — 70W across 5m against the flex's 144W across 20m. So it is not simply a current limit, or 70W would carry further than 144W rather than a quarter as far. The COB strip's conductors must be lighter.

What does that mean for my layout?

It changes it. A 12 metre kitchen run is one PLEO flex and one driver, or three COB sections with three feeds — three driver locations to find, three cable routes, and three things to fail. That is the trade nobody states: COB for a short run seen close where dotless matters, flex for a long run where reach matters more than the last degree of smoothness.

What is a 50m pack actually for?

A project rather than a room. At a 5 metre single-feed limit, 50 metres is ten runs — or five fed from both ends — so it suits a fitout with the same detail repeated through many spaces, bought once and cut on site. It also means ten drivers, or five, and that is the cost line people miss when comparing COB against a longer-reaching product.

What do you need from me to quote it?

The total metreage and the number of separate runs. The second figure is the one that sets the driver count, and metreage alone does not carry it. On a 50m pack that is the difference between five drivers and ten.

Why 25mm cutting increments?

Because at 840 LEDs per metre one sits every 1.19mm, and 25mm holds 21 of them — so a cut segment is a block of 21 LEDs and 25mm is where that block ends. It is finer than the PLEO flex's 50mm increment, so your run rounds to half the error, which on lettering or a detail butting into a return is a real advantage.

What else do I need?

A 24V DC driver per run and a colour controller. Domus names the CHAM-BT-RF-5C 5 Channel Controller and LED Driver, which is unusual in this catalogue — most strip listings name nothing. Five channels is more than RGB requires, so the same controller covers tuneable-white and RGB+TW strips too.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUPLEX-RGB COB IP54 50M Pack — 24157
⭐⭐ MAX RUN 5 m ONE FEED · 10 m BOTH ENDS⭐ Published outright
⚠ Against the PLEO flex's 20 m / 40 m⭐ A QUARTER of the reach
⭐⭐ AND IT CARRIES HALF THE TOTAL WATTS70 W over 5 m vs the flex's 144 W over 20 m
⭐ So it is NOT simply a current limit⚠ The COB strip's conductors must be lighter
⭐⭐ THE CONSEQUENCE CHANGES LAYOUTS⭐ A 12 m kitchen run = ONE flex — ⚠ or THREE COB sections
⚠ Which meansThree driver locations · three cable routes · ⭐ three things to fail
⭐ THE HONEST CHOICECOB for a short run seen CLOSE — ⭐ flex for REACH
⭐ A 50 m pack is TEN runsOr five fed both ends — ⚠ and ten drivers, or five
⭐ Tell us total metreage AND run count⭐ The second sets the driver count
⭐ 25 mm cut increment⭐ A block of 21 LEDs — ⭐ half the flex's 50 mm rounding error
⭐ Controller namedCHAM-BT-RF-5C, 5 channel

Variant specifications

⭐ PLEX COBPLEO flex 7.2W
⭐ Run, one feed⭐ 5 m⭐ 20 m
Total watts70 W144 W
⭐ Density⭐ 840 / m140 / m
⭐ Cut⭐ 25 mm50 mm
