Domus Lighting LED Strip Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Domus Lighting LED Strip Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 23955

Domus PLEX-COB Opposite Wiring Live Cable 500mm Tail 5 Pack Single Colour

Color Temprature Changing Technology
Color Temprature Changing Technology
$12.95
$12.95
Product Description
Product Description
x

The Domus PLEX-COB Opposite Wiring Live Cable is a reversed-polarity strip-to-driver connector — 500 mm tail, 5 pack, for single colour, tuneable, RGB, RGBTW or Micro strip.

⭐⭐ What “opposite wiring” is, and why you need it
  • ⭐ An LED strip has a DIRECTION. ⭐ Its conductors run in a fixed order along its length, and a connector has to meet them in that order.
  • ⭐ A standard live cable is made to attach at one end. ⚠ Attach the same connector at the OTHER end and the conductors meet in mirror image — ⭐ the polarity reverses, and on a multi-channel strip the colour channels swap.
  • ⭐ An opposite-wiring connector is built with the contacts reversed, so it presents the right conductor to the right pad when it is attached from the far end.
  • ⭐⭐ THE REASON THIS MATTERS ON THIS RANGE: the PLEX COB strip publishes a 5 m limit from one feed and 10 m fed from BOTH ENDS. ⭐ Doubling the run means feeding from the far end — ⭐ and the far end is exactly where a standard connector would be mirrored. ⭐ So this accessory is what makes the 10 m figure achievable.
  • ⚠ Nothing on the strip listing mentions it. ⭐ The 10 m run and the connector that enables it are on different pages, and neither points at the other.
⛔ Its title names one of its five variants
  • ⭐ The title reads “…5 Pack Single Colour”. ⛔ Its variants are Single Colour, Tuneable, RGB, RGBTW and Micro.
  • ⚠ So a buyer searching for an opposite-wiring connector for an RGB strip has no reason to open a listing that says “Single Colour”, ⭐ and would reasonably conclude one does not exist.
  • ⭐ It does. This listing carries all five.
  • ⚠ And the connector listings are structured inconsistently across the range: ⭐ two of them are single-type listings (an RGB one and an RGB+TW one), while this one and the straight joiner carry the type as a variant. ⭐ So there is no single place to look and no consistent way to search.
⭐ Five types, and matching one to your strip

⭐ Single colour, tuneable, RGB, RGBTW and Micro. ⭐ They are not interchangeable, because each strip type carries a different number of conductors — ⭐ two for single colour, three for tuneable, four for RGB, six for RGBTW. ⭐ Tell us the strip and we will send the right one. ⚠ Ordering by tail length alone is how the wrong variant arrives.

⭐ 500 mm tail — the shortest in the range

⭐ The family spans 500 mm to 2 m. ⭐ 500 mm suits a driver in the same cabinet or immediately behind the detail — ⚠ which on a far-end feed is a real constraint, because the far end is the end furthest from wherever you put the first driver. ⭐ If you are feeding both ends of a 10 m run, you need driver locations at BOTH ends, ⭐ and a 500 mm tail gives you very little room to find one. ⭐ The 2 m tail versions exist for exactly this.

✅ What is published
Specification Value
⭐ Function ⭐ Opposite wiring — ⭐ feeds a strip from the far end
⭐ What it enables ⭐ The published 10 m both-ends run
⭐ Variants ⭐ Single colour · tuneable · RGB · RGBTW · Micro
⛔ Title ⛔ Names only “Single Colour” — ⚠ one of five
Tail 500 mm — ⚠ the shortest; ⭐ 2 m versions exist
Pack 5 connectors
⭐ Installation ⭐ Solderless — a pair of pliers · ⭐ 4.64 kgf
⭐ Fits inside the profile ⭐ Yes
⛔ Colour temperature field ⛔ Publishes “RGB” on a five-type listing
⛔ Cross-reference from the strip page ⛔ None — ⚠ the 10 m run and this connector never meet
⛔ Made to order — and the "cut to length" part is not about this product

Domus flags this as made to order, so it is not held on a shelf. ⛔ No lead time is published. Call our team to confirm availability before ordering. ⭐ We will. ⚠ The flag also says "cut to length", which comes from a generic sentence about the STRIP — ⭐ a connector cannot be cut to length, and nothing about the lead time depends on that.

Where it works
  • ⭐ Feeding the far end of a run — ⭐ what it exists for.
  • ⭐ Achieving the 10 m both-ends figure.
  • ⭐ Any of the five strip types — ⭐ matched variant.
  • ⚠ Not with a driver more than 500 mm away — ⭐ take a 2 m tail.
  • ⚠ Not ordered by tail length alone.
Specifying it

Solderless opposite-wiring live cable connector for PLEX-COB LED strip, 500 mm tail, 5 pack. Single colour, tuneable, RGB, RGBTW or Micro. Pliers only, no soldering. Pulling force 4.64 kgf. Fits inside the profile. ⭐⭐ AN LED STRIP HAS A DIRECTION — its conductors run in a fixed order, so a standard connector attached at the FAR end meets them mirrored and the polarity reverses. This one has the contacts reversed to match. ⭐ AND THAT IS WHAT MAKES THE STRIP'S PUBLISHED 10 m BOTH-ENDS RUN ACHIEVABLE — yet nothing on the strip listing mentions it, and neither page points at the other. ⛔ ITS TITLE ALSO NAMES ONLY "Single Colour" while it carries five types.

Supplied and supported by Lights For You.

Questions
What does "opposite wiring" mean?

That the contacts are reversed. An LED strip has a direction: its conductors run in a fixed order along its length, and a connector has to meet them in that order. A standard live cable is made to attach at one end — attach the same connector at the other end and the conductors meet in mirror image, so the polarity reverses and on a multi-channel strip the colour channels swap. This connector is built to present the right conductor to the right pad from the far end.

When do I need one?

Whenever you feed a run from its far end — and on this range that is not an edge case. The PLEX COB strip publishes a 5 metre limit from one feed and 10 metres fed from both ends. Doubling the run means feeding from the far end, and the far end is exactly where a standard connector would be mirrored. So this accessory is what makes the 10 metre figure achievable.

Is that connection made anywhere in the catalogue?

No. The 10 metre run figure is on the strip listing and this connector is on its own page, and neither points at the other. Someone reading the strip listing would plan a both-ends feed with no idea a special connector is required for it.

Why does the title say "Single Colour"?

It should not. The variants are Single Colour, Tuneable, RGB, RGBTW and Micro — five types on one listing, with the title naming one. So a buyer searching for an opposite-wiring connector for an RGB strip has no reason to open a listing that says "Single Colour", and would reasonably conclude one does not exist. It does.

Are the connector listings consistent?

No, and that compounds it. Two of them are single-type listings — an RGB one and an RGB+TW one — while this one and the straight joiner carry the type as a variant. So there is no single place to look and no consistent way to search across the accessory range.

Can I use any variant with any strip?

No. Each strip type carries a different number of conductors — two for single colour, three for tuneable, four for RGB, six for RGBTW — so the variants are not interchangeable. Tell us the strip and we will send the right one. Ordering by tail length alone is how the wrong variant arrives.

Is a 500mm tail long enough?

On a far-end feed it may not be. The family spans 500mm to 2m, and 500mm suits a driver in the same cabinet or immediately behind the detail. But the far end of a 10 metre run is the end furthest from wherever you put the first driver, so you need a second driver location there — and 500mm gives you very little room to find one. The 2m tail versions exist for exactly this.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsPLEX-COB Opposite Wiring 500mm 5 Pack — 23955 Single Colour, 23956 Tuneable, 23957 Rgb, 23958 Rgbtw, 23959 Micro
⭐⭐ AN LED STRIP HAS A DIRECTION⭐ Its conductors run in a FIXED ORDER
⚠ A standard connector at the FAR end⭐ Meets them MIRRORED — ⚠ polarity reverses, channels swap
⭐ This one has the contacts reversed⭐ So it presents the right conductor to the right pad
⭐⭐ AND IT IS WHAT MAKES THE 10 m RUN ACHIEVABLE⭐ The strip publishes 5 m one feed, 10 m BOTH ENDS
⛔ Yet nothing on the strip listing mentions it⚠ Neither page points at the other
⛔ ITS TITLE NAMES ONLY "Single Colour"⭐ Its variants are FIVE types
⚠ So a buyer wanting RGBHas no reason to open it — ⭐ and concludes one does not exist
⚠ The connector listings are inconsistent⭐ Two are single-type · ⭐ two carry the type as a variant
⭐ Five types, not interchangeable2 / 3 / 4 / 6 conductors — ⭐ tell us the strip
⚠ 500 mm is the SHORTEST tail⭐ On a far-end feed you need a second driver location — ⭐ 2 m versions exist
⭐ Solderless · 4.64 kgf · fits the profile⭐ Pliers only

Variant specifications

Feed positionConnector⭐ Run achieved
One endStandard live cable5 m
⭐ Both ends⭐ + opposite wiring⭐ 10 m
⚠ Far end, standard⛔ Mirrored⛔ Will not work
