Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 24014

Domus PLEX-COB-5-20M - 20M Roll Pack 5W LED Per Metre 640LED True Dotless Striplight IP54 24V - DRIVER REQUIRED

3 Years Warranty
3 Years Warranty
IP54 – dust and splashproof
IP54 – dust and splashproof
Color Temprature Changing Technology
Color Temprature Changing Technology
Beam angle for focused or wide lighting
180° Beam angle for focused or wide lighting
Dimmable
Dimmable
$422.95
$546.00
$422.95
Product Description
Product Description
x

The Domus PLEX-COB-5-20M is a 24 V COB LED strip — 5 W per metre, 640 LEDs per metre, CRI ≥90, IP54, 20 m roll, in 3000, 4000 or 5000 K at 450 / 500 / 500 lm per metre.

⭐⭐ Twenty metres is two runs, not four — if you feed from both ends
  • ⭐ The sheet gives two limits, not one: “Continuous Run: 5 m Max (one end driver feed) 10 m (two end driver feed)”.
  • ⭐ Feeding a length from both ends halves the current each half carries, so the voltage drop halves too. ⭐ Same strip, same driver, one extra cable run — and twice the unbroken length.
20 m of PLEX-COB-5 Runs Cuts Drivers ⭐ Feed cables
One-end feed 4 3 4 × 30 W 4
⭐ Two-end feed ⭐ 2 ⭐ 1 ⭐ 2 × 60 W 4
  • ⭐ HALF THE DRIVERS, A THIRD OF THE CUTS, AND THE SAME NUMBER OF CABLES — ⭐ because a two-end run needs two cables where a one-end run needs one. ⭐ So the wiring effort is identical and everything else halves.
  • ⭐ It is close to free, and nothing on the listing mentions it. ⭐ The figure is inside the PDF, in a line most people will not reach.
  • ⚠ The one condition: both feeds must come from the same driver, or from drivers that are genuinely matched. ⭐ Tell us the run and we will size it properly.
⛔⛔ And it must be on an aluminium heat sink, or the warranty is void

⭐ The datasheet states it in capitals, and seventeen strip sheets in the range repeat it. ⛔ Zero descriptions say it; zero of the catalogue's 47 aluminium profiles mention PLEX-COB. ⭐ Twenty metres of strip therefore means twenty metres of profile too — ⚠ a material cost that has to be in the budget from the start, not discovered at installation. ⭐ Ask us to quote both together.

⭐ At last, real output figures

⭐ The sheet publishes per-metre lumens: 3000 K 450 lm, 4000 K 500 lm, 5000 K 500 lm — ⭐ so 90 to 100 lumens per watt, which is respectable for CRI ≥90. ⭐ High colour rendering always costs efficiency; getting 100 lm/W alongside CRI90 is a good balance rather than a compromise. ⭐ Over twenty metres that is 9,000 to 10,000 lumens for 100 W — ⭐ the equivalent of roughly ten to twelve downlights, spread as a continuous line.

✅ What is published
Specification Value
⛔ Aluminium heat sink ⛔ MANDATORY — omitting it VOIDS THE WARRANTY
⭐ Output ⭐ 450 / 500 / 500 lm per metre — ⭐ 90–100 lm/W
Total for the roll ⭐ 9,000–10,000 lm for 100 W
⭐ Continuous run 5 m one-end · ⭐ 10 m two-end
⭐ So 20 m needs ⭐ 2 drivers, not 4 — ⭐ two-end feed
⭐ Cutting increment ⭐ 25 mm
LED density / CRI 640 per metre, dotless · CRI ≥90
Beam / wiring / dimmable 180° · parallel · ⭐ yes
Lifespan 50,000 hours — ⭐ assumes the heat sink
⛔ Driver ⛔ 24 V DC constant voltage — required
Where it works
  • ⭐ Long domestic and retail runs — ⭐ 5 W is usually enough.
  • ⭐ Two-end feeds — ⭐ half the drivers for one extra cable.
  • ⭐ Where a profile is already in the budget.
  • ⛔ Never loose or on plasterboard.
  • ⚠ Not where 20 m must be unbroken — ⭐ 10 m is the ceiling.
Specifying it

COB LED strip, 20 m roll. 5 W per metre at 24 V DC, 100 W total. 450 lm at 3000 K, 500 lm at 4000 and 5000 K. 640 LEDs per metre, dotless. CRI ≥90. IP54. 180° beam. 25 mm cutting increment. Continuous run 5 m one-end, 10 m two-end. Dimmable. 3-year warranty. ⭐⭐ TWENTY METRES IS TWO RUNS AND TWO DRIVERS, NOT FOUR — feeding each length from both ends halves the current per half and doubles the unbroken run to 10 m. Same strip, same total cable, half the drivers and a third of the cuts. ⭐ It is close to free, and the figure sits inside a PDF where most people will never reach it. ⛔ AND THE STRIP MUST BE MOUNTED ON AN ALUMINIUM HEAT SINK OR THE WARRANTY IS VOID — so twenty metres of strip means twenty metres of profile in the budget.

Supplied and supported by Lights For You.

Questions
How many drivers does 20 metres need?

Two, if you feed each run from both ends. The sheet gives two limits — 5 metres from one end, 10 metres from two — so twenty metres is either four runs on one-end feeds or two runs on two-end feeds. Two runs means half the drivers and a third of the cuts.

Does the two-end feed cost more cable?

No, that is the good part. A two-end run needs two cables where a one-end run needs one, so across twenty metres you run four feed cables either way. The wiring effort is identical and the driver count halves. It is close to free.

Why does feeding both ends work?

Because it halves the current each half of the run carries, and voltage drop follows current. The far end of a one-end 10 metre run would be dim; fed from both ends, the weakest point is the middle and it is only carrying half as much.

Is there a condition?

Both feeds must come from the same driver, or from drivers that are genuinely matched. Mismatched supplies fighting each other across a strip is the one way to get this wrong. Tell us the run and we will size it properly.

Does it need an aluminium profile?

Yes — the datasheet states in capitals that all LED strip must be installed on an aluminium heat sink and that failure to do so will void the warranty, and seventeen strip sheets repeat it. Zero descriptions say it and zero of the catalogue's 47 profiles mention PLEX-COB. Twenty metres of strip means twenty metres of profile too, and that is a material cost that belongs in the budget from the start.

How much light does the roll give?

450 lumens per metre at 3000K and 500 at 4000 and 5000K, so 9,000 to 10,000 lumens across the roll for 100 watts. That is roughly ten to twelve downlights' worth, spread as a continuous line.

Is 90 to 100 lm/W good?

For CRI ≥90, yes. High colour rendering always costs efficiency — the phosphors that fill in the colour spectrum absorb light doing it — so getting 100 lm/W alongside CRI90 is a good balance rather than a compromise. A CRI80 strip would be brighter per watt and noticeably worse on skin tones and timber.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsPLEX-COB-5-20M — 24014 3000K, 24015 4000K, 24016 5000K
⭐⭐ 20 m = TWO runs and TWO drivers⚠ Not four — ⭐ if fed from both ends
⭐ The sheet gives TWO limits5 m one-end feed · ⭐ 10 m TWO-END feed
⭐ Two-end halves the current per half⭐ So the drop halves too
⭐⭐ AND THE CABLE COUNT IS IDENTICAL⭐ 4 feed cables either way — ⭐ so it is close to FREE
⭐ One-end: 4 runs · 3 cuts · 4 × 30 W⭐ Two-end: 2 runs · 1 cut · 2 × 60 W
⚠ The one condition⭐ Both feeds from the same driver, or genuinely matched drivers
⛔ Aluminium heat sink⛔ MANDATORY — ⭐ 20 m of strip = 20 m of profile in the budget
⭐ Output⭐ 450 / 500 / 500 lm per metre — ⭐ 90–100 lm/W
⭐ Roll total⭐ 9,000–10,000 lm for 100 W — ⭐ ~10–12 downlights as a line
⭐ 100 lm/W alongside CRI ≥90⭐ A good balance — ⚠ high CRI always costs efficiency

Variant specifications

20 m of PLEX-COB-5RunsCuts⭐ Drivers
One-end feed434 × 30 W
⭐ Two-end feed⭐ 2⭐ 1⭐ 2 × 60 W
⭐ Feed cables44⭐ Identical
