Domus Lighting LED Strip Domus PLEX-COB-20 Strip IP54 CRI90 24V 640LED/M 5M Pack
Domus Lighting LED Strip Domus PLEX-COB-20 Strip IP54 CRI90 24V 640LED/M 5M Pack
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 24093

Domus PLEX-COB-20 Strip IP54 CRI90 24V 640LED/M 5M Pack

IP54 – dust and splashproof
IP54 – dust and splashproof
$160.95
$160.95
Product Description
Product Description
x

The Domus PLEX-COB-20 is a 24 V COB LED strip — 20 W per metre, 640 LEDs per metre, CRI90, IP54, 5 m pack, in 3000, 4000 or 5000 K.

⭐ 20 W is where the driver stops being a detail
  • ⭐ Five metres at 20 W is 100 W, so a 120 W driver. ⭐ Compare the same five metres at the other wattages:
Strip 5 m load Driver ⭐ Where it can live
PLEX-COB-5 25 W ⭐ 30 W ⭐ Inside joinery, behind a panel
PLEX-COB-10 50 W 60 W ⭐ A cupboard or ceiling void
PLEX-COB-15 75 W 90 W ⚠ A cupboard, ventilated
⭐ PLEX-COB-20 — this one ⭐ 100 W ⭐ 120 W ⛔ Its own space — ventilated and accessible
  • ⭐ Somewhere between the 10 W and 20 W strips, the driver crosses from “a thing you hide” to “a piece of equipment that needs planning”. ⭐ At 120 W it is roughly the size of a large paperback, it generates real heat, and it wants ventilation.
  • ⚠ That is a design consequence of a lighting choice, and nothing in the catalogue mentions it. ⭐ The wattage looks like a brightness decision on the page and turns into a joinery decision on site.
  • ⭐ THE TEST TO APPLY BEFORE ORDERING: is there a ventilated, accessible, dry space within about two metres of the run? ⭐ If not, the 10 W strip halves the problem and gives half the light — ⭐ which for most positions is still more than enough.
⭐ And it is the same run limit, which makes 20 W the least efficient use of it

⭐ The published single-feed limit is 5 m for the range. ⚠ At 20 W that five metres carries 100 W; at 5 W it carries 25. ⭐ So the strip with the highest load gets the least distance per driver, and the drop across the run is worst — ⭐ because current scales with load. ⭐ Treat 5 m as a ceiling at this wattage rather than a comfortable figure, and ask us before running it full length.

⭐ IP54 — what it actually covers

⭐ Domus's own framing: IP54 is “indoor strip including wet areas”. ⭐ So kitchens, bathrooms and laundries are covered — steam and splashing. ⛔ What is not covered is water arriving with force or sitting: hosing, a mopped floor detail, an outdoor position. ⭐ Those want the IP67 version, ⚠ which carries a silicon coating and the cutting limitation that comes with it. ⭐ For a normal kitchen bench, IP54 is the right answer and the easier product.

✅ What is published
Specification Value
Load ⭐ 20 W per metre — ⭐ 100 W for the pack
⭐ Driver ⭐ ≈120 W — ⚠ needs its own ventilated space
⭐ Format ⭐ 5 m pack — ⭐ exactly one run, no cuts
⭐ LED density ⭐ 640 per metre — ⭐ identical across all four wattages
Colour rendering ⭐ CRI90
Colour temperature 3000, 4000 or 5000 K
IP rating IP54 — ⭐ indoor including wet areas
⚠ Reach ⚠ Shortest in the range — ⭐ 5 m is a ceiling here
⛔ Warranty · beam · dimmable ⛔ Not on this line — ⭐ 3 years, 180°, yes
⛔ Driver ⛔ Required, not included
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Kitchen benches worked at daily — ⭐ the highest output available.
  • ⭐ Where a 120 W driver has a home.
  • Wet areas — ⭐ IP54 covers steam and splashing.
  • ⛔ Not where the driver has nowhere ventilated to live.
  • ⚠ Not a full 5 m single feed without asking us.
Specifying it

COB LED strip, 5 m pack. 20 W per metre at 24 V DC, 100 W total. 640 LEDs per metre, dotless. CRI90. 3000, 4000 or 5000 K. IP54. Driver required, approximately 120 W. ⭐ 20 W IS WHERE THE DRIVER STOPS BEING A DETAIL. Five metres at 5 W needs a 30 W driver you can hide in joinery; at 20 W it needs 120 W — roughly a large paperback, generating real heat, wanting ventilation and its own accessible space. ⭐ THAT IS A JOINERY DECISION DISGUISED AS A BRIGHTNESS ONE, and nothing in the catalogue mentions it. ⭐ THE TEST: is there a ventilated, accessible, dry space within about two metres of the run?

Supplied and supported by Lights For You.

Questions
What driver does a 5 metre run need?

At 20W per metre, 100 watts of load, so a 120W driver. That is roughly the size of a large paperback, it generates real heat, and it wants ventilation. Compare the same five metres at the other wattages: 5W needs a 30W driver you can hide in joinery, 10W needs 60W, 15W needs 90W.

So the wattage changes where the driver goes?

Yes, and that is the point people miss. Somewhere between the 10W and 20W strips, the driver crosses from a thing you hide to a piece of equipment that needs planning. It is a joinery decision disguised as a brightness one, and nothing in the catalogue mentions it.

What test should I apply before ordering?

Is there a ventilated, accessible, dry space within about two metres of the run? If not, the 10W strip halves the problem and gives half the light — which for most positions is still more than enough. Let the driver location influence the wattage rather than discovering the conflict on site.

Does 20W get less out of the run limit?

Yes. The published single-feed limit is 5 metres for the range, and at 20W that five metres carries 100W where at 5W it carries 25. So the strip with the highest load gets the least distance per driver, and the drop across the run is worst — because current scales with load. Treat 5 metres as a ceiling at this wattage and ask us before running it full length.

What does IP54 cover?

Domus's own framing is "indoor strip including wet areas" — so kitchens, bathrooms and laundries, meaning steam and splashing. What it does not cover is water arriving with force or sitting: hosing, a mopped floor detail, an outdoor position. Those want the IP67 version, which carries a silicon coating and the cutting limitation that comes with it.

Should I take IP67 to be safe?

Not for a normal kitchen bench. IP54 is the right answer and the easier product — the IP67 coating means every cut breaks the seal, so over-specifying costs you a constraint as well as money. Match the rating to what the position actually delivers.

Will it look different from the lower wattages?

No. All four PLEX-COB wattages carry the same 640 LEDs per metre and are equally dotless, so they look identical and differ only in output. That means you can mix wattages across a job — 20W over the bench, 5W in the cove — without any visual inconsistency.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsPLEX-COB-20 IP54 5M Pack — 24093 3000K, 24094 4000K, 24095 5000K
⭐⭐ 20 W IS WHERE THE DRIVER STOPS BEING A DETAIL⭐ 5 m = 100 W → ⭐ a 120 W driver
⭐ PLEX-COB-5 over 5 m25 W → ⭐ a 30 W driver you can HIDE in joinery
⭐ PLEX-COB-1050 W → 60 W — a cupboard or ceiling void
⭐ PLEX-COB-20 (this)⭐ 100 W → ⭐ 120 W — ⛔ its own VENTILATED, accessible space
⚠ Roughly a large paperback⭐ Generating real heat
⭐⭐ A JOINERY DECISION DISGUISED AS A BRIGHTNESS ONE⚠ And nothing in the catalogue mentions it
⭐⭐ THE TEST BEFORE ORDERING⭐ Is there a ventilated, accessible, DRY space within ~2 m?
⭐ If not⭐ The 10 W strip halves the problem and gives half the light
⚠ 20 W also gets LEAST from the run limit⭐ 5 m carries 100 W here — ⭐ 25 W on the 5 W strip
⭐ IP54 = "indoor including wet areas"⭐ Steam and splashing — ⛔ not hosing, mopping or outdoors
⭐ All four wattages look IDENTICAL⭐ 640 LEDs/m — ⭐ so mixing across a job is free

Variant specifications

Strip5 m loadDriver⭐ Where it lives
⭐ COB-525 W⭐ 30 W⭐ Hidden in joinery
COB-1050 W60 WA cupboard
COB-1575 W90 W⚠ Ventilated cupboard
⭐ COB-20⭐ 100 W⭐ 120 W⛔ Its own space
