Domus Lighting LED Neon Flex Domus PLEO-9.6 Neon Micro Side 24V IP67 CRI90 20M
Domus Lighting LED Neon Flex Domus PLEO-9.6 Neon Micro Side 24V IP67 CRI90 20M
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 21412

Domus PLEO-9.6 Neon Micro Side 24V IP67 CRI90 20M

IP67 – waterproof to 1m depth
IP67 – waterproof to 1m depth
$1,063.95
$1,063.95
Product Description
Product Description
x

The Domus PLEO-9.6 Micro Side is a 24 V side-emitting LED neon flex — 9.6 W per metre, CRI90, IP67, 20 m reel, in 3000, 4000 or 5000 K.

⭐ The whole PLEO decision, in one place

⭐ Choosing a PLEO flex means four separate decisions, and no listing in the catalogue puts them together.

Decision Options ⭐ What actually decides it
1. Wattage 7.2 · ⭐ 9.6 · 14.4 W/m ⭐ RUN LENGTH, not brightness — ⭐ only 7.2 publishes a limit
2. Emission Top · ⭐ Side ⭐ Whether the curve is drawn on a flat plane
3. Size Standard · ⭐ Micro ⭐ Beam — 165° standard, 110° micro
4. Format 1 m · ⭐ 20 m reel ⭐ Sample first, then buy the reel
  • ⭐ The wattage decision is the one people get backwards. ⚠ It reads as a brightness choice and it is really a REACH choice — ⭐ 7.2 W/m carries 20 m from one feed, and higher wattages draw more current and carry less. ⭐ Decide the run length first, then the wattage.
  • ⭐ This product is the 9.6 W middle, side-emitting, Micro, on a reel — ⭐ so it suits a moderate-length run, curved on a flat plane, sitting inside a channel or reveal, bought as one continuous piece. ⭐ That is a specific and coherent combination.
⭐ Micro plus side view — a narrow beam from a narrow edge

⭐ Micro publishes a 110° beam against the standard's 165°, ⭐ and side view emits from the edge rather than the face. ⭐ Together those give the most contained line in the range — ⭐ which is what you want inside a routed groove or a narrow reveal, where a wide beam simply lights the groove's own walls. ⚠ It is the least useful combination for an exposed outline meant to be seen from every angle, ⭐ where the standard top view at 165° is the answer.

⛔ What this listing does not publish
  • ⛔ The maximum run at 9.6 W/m. ⭐ Only the 7.2 states one. ⭐ Since drop is driven by current, 9.6 carries less than 20 m from one feed — ⚠ an inference, not a figure. ⭐ Ask us beyond about 12 m.
  • ⛔ The section dimensions — ⚠ awkward on a product whose defining feature is being smaller, and the figure that would pair it to a profile. ⭐ Only two of the nineteen PLEO flex listings state a section.
  • ⛔ The lumen output and the driver. ⭐ Driver sizing is straightforward: 9.6 W/m × your metres, plus about a fifth.
✅ What is published
Specification Value
Load 9.6 W per metre at 24 V DC
Emission ⭐ Side view — ⭐ from the edge
Size ⭐ Micro — ⭐ 110° beam against the standard's 165°
Colour rendering ⭐ CRI90
Colour temperature 3000 / 4000 / 5000 K
IP rating ⭐ IP67
⭐ LED density / cut ⭐ 140 SMD LEDs per metre · ⭐ 50 mm increments
Format 20 m reel — ⭐ one continuous piece
⛔ Maximum run · section · lumens ⛔ Not published
Warranty ⭐ 3 years
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Inside routed grooves and narrow reveals — ⭐ the most contained line offered.
  • ⭐ Curves drawn on a flat plane — ⭐ side emission follows them.
  • Moderate-length continuous runs.
  • ⚠ Not an exposed outline — ⭐ take the standard top view at 165°.
  • ⛔ Not over ~12 m on one feed without asking us.
Specifying it

Side-emitting Micro 24 V DC LED neon flex, 20 m reel. 9.6 W per metre. 140 SMD LEDs per metre, cut in 50 mm increments. 110° beam. CRI90. 3000 / 4000 / 5000 K. IP67. 3-year warranty. ⭐ CHOOSING A PLEO FLEX MEANS FOUR DECISIONS AND NO LISTING PUTS THEM TOGETHER: wattage, emission, size and format. ⭐ THE WATTAGE ONE IS THE ONE PEOPLE GET BACKWARDS — it reads as a brightness choice and is really a REACH choice, since 7.2 W/m carries 20 m from one feed and higher wattages carry less. ⭐ Decide the run length first, then the wattage. ⭐ Micro plus side view gives the most contained line in the range, which is what a routed groove needs.

Supplied and supported by Lights For You.

Questions
How do I choose a PLEO flex?

Four decisions, and no listing in the catalogue puts them together. The wattage — 7.2, 9.6 or 14.4W per metre. The emission — top or side. The size — standard or Micro. And the format — a 1m sample or a 20m reel.

Which of those is most often got wrong?

The wattage. It reads as a brightness choice and it is really a reach choice: 7.2W/m carries 20 metres from one feed, and higher wattages draw more current and carry less. Decide the run length first, then the wattage — not the other way round.

What decides top versus side?

Whether the curve is drawn on a flat plane. A top-emitting flex fires from its wide face and follows a cove or a section curve; forced round a curve drawn on a floor or wall it twists. Side view emits from the edge and follows a flat curve naturally.

What decides standard versus Micro?

The beam. Micro publishes 110 degrees against the standard's 165 — noticeably tighter, so more light goes forward and less spills sideways. Inside a routed groove or a narrow reveal that is what you want, because a wide beam simply lights the groove's own walls.

So what is this particular combination for?

A moderate-length run, curved on a flat plane, sitting inside a channel or reveal, bought as one continuous piece. Micro plus side view gives the most contained line in the range. It is the least useful combination for an exposed outline meant to be seen from every angle — there the standard top view at 165 degrees is the answer.

How long a run can I have at 9.6W?

Not published. Only the 7.2W version states a limit — 20 metres from one feed, 40 from both. Since voltage drop is driven by current, 9.6 carries less than 20 metres from one feed, though that is an inference rather than a figure. Ask us beyond about 12 metres.

What else is missing?

The section dimensions, which is awkward on a product whose defining feature is being smaller — and it is the figure that would pair it to a profile. Only two of the nineteen PLEO flex listings state a section. Also the lumen output. Driver sizing is straightforward: 9.6W per metre times your metres, plus about a fifth.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsPLEO-9.6 Micro Side 20M — 21412 3000K, 21413 4000K, 21414 5000K
⭐ FOUR DECISIONS, AND NO LISTING ASSEMBLES THEMWattage · emission · size · format
⭐⭐ THE WATTAGE ONE IS GOT BACKWARDS⚠ It reads as BRIGHTNESS and is really REACH
⭐ 7.2 W/m carries 20 m from one feed⚠ Higher wattages draw more current and carry LESS
⭐ So decide the RUN LENGTH firstThen the wattage
⭐ Emission decided byWhether the curve is drawn on a FLAT PLANE
⭐ Size decided byThe BEAM — ⭐ 165° standard, 110° Micro
⭐ Micro + side view⭐ The most CONTAINED line in the range
⭐ Which is what a routed groove needs⚠ A wide beam just lights the groove's own walls
⚠ The least useful for an exposed outline⭐ There take the standard top view at 165°
⛔ Maximum run at 9.6 W/mNot published — ⭐ ask us beyond ~12 m
⛔ Section dimensionsNot published — ⚠ awkward on a product whose feature is being SMALLER

Variant specifications

DecisionOptions⭐ Decided by
⭐ Wattage7.2 / 9.6 / 14.4⭐ RUN LENGTH
EmissionTop / side⭐ Curve on a plane?
SizeStandard / Micro⭐ Beam: 165° / 110°
Format1m / 20m reel⭐ Sample, then reel
