Domus PLEO-7.2W Neon Top View 10X10MM 24V IP67 CRI90 1m

The Domus PLEO-7.2 Top View is a 24 V top-emitting LED neon flex — 10 × 10 mm section, 7.2 W per metre, CRI90, IP67, 1 m, in 3000, 4000 or 5000 K.

⭐ A square flex in a square profile — orientation stops mattering

• ⭐ This flex is 10 × 10 mm: SQUARE. ⭐ And Domus's 10 × 10 mm Pleo profile is square too.
• ⭐ That combination has a property none of the others has: it presents the same face however it is rotated. ⭐ A run that goes from horizontal under a shelf to vertical up a return reads consistently along its whole length.
• ⚠ A 6.5 × 11 mm flex in a 6.5 × 11 mm profile does not. ⭐ Rotate that assembly 90° and it presents a different width to the eye — ⭐ so a run that changes plane looks like two different products joined together.
• ⭐ So for anything that turns a corner out of its plane, the square 10 × 10 combination is the one to specify. ⭐ It is a small property with a visible result.

⭐ Top view at 10 × 10 — the general-purpose choice

⭐ Top-emitting flex fires from its wide face, so in a cove it lies flat and points up — ⭐ the correct orientation for bouncing light off a ceiling. ⭐ Combined with a 10 mm section that takes a profile comfortably, and the 7.2 W long-run wattage, this is the most generally useful flex in the range — ⭐ a cove, a shelf line, a soffit detail, a stair nosing, all from one product. ⚠ What it will not do is follow a curve drawn on a flat plane, ⭐ which is what side view exists for.

⭐ 7.2 W — and the only published run figure in the range

⭐ Its 20 m sibling publishes up to 20 m of continuous light from one driver feed, or 40 m powered from both ends. ⭐ That is the only run figure published anywhere in the PLEO range, ⚠ and it applies to this wattage. ⭐ The 9.6 and 14.4 W versions draw more current and will carry less — ⭐ so if a long run is the requirement, 7.2 is the wattage that has a stated answer.

✅ What is published

⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works

• ⭐ Runs that change plane — ⭐ square reads consistently.
• Ceiling coves, shelf lines, soffit details, stair nosings.
• ⭐ Long runs — ⭐ the only published run figure.
• ⛔ Not round a curve drawn on a plane — ⭐ take side view.
• ⛔ Not in a 6.5 × 11 profile — ⚠ it will not fit.

Specifying it

Top-emitting 24 V DC LED neon flex, 10 × 10 mm square section, 1 m. 7.2 W per metre. 140 SMD LEDs per metre, cut in 50 mm increments. CRI90. 3000 / 4000 / 5000 K. IP67. Order code PLEO-7.2-T. ⭐ A SQUARE FLEX IN A SQUARE PROFILE IS ORIENTATION-INDEPENDENT — it presents the same face however it is rotated, so a run that goes from horizontal under a shelf to vertical up a return reads consistently. ⚠ A 6.5 × 11 assembly rotated 90° presents a different width to the eye, so a run that changes plane looks like two products joined. ⭐ FOR ANYTHING THAT TURNS OUT OF ITS PLANE, SPECIFY THE SQUARE COMBINATION.

Supplied and supported by Lights For You.
