Domus PLEO-7.2W Neon Side View 6.5X11MM 24V IP67 CRI90 1m

The Domus PLEO-7.2 Side View is a 24 V side-emitting LED neon flex — 6.5 × 11 mm section, 7.2 W per metre, CRI90, IP67, 1 m, in 3000, 4000 or 5000 K.

⭐⭐ Its title states the section — and only two of nineteen do

• ⭐ This listing says “6.5X11MM” in its title. ⭐ That number is the single most useful thing on the page, because it is what pairs the flex to a profile.
• ⭐ Domus sells Pleo aluminium profiles in three sections — 4 × 8, 6.5 × 11 and 10 × 10 mm. ⭐ A 6.5 × 11 mm flex goes in a 6.5 × 11 mm profile. That is the whole rule.
• ⛔ We counted: of 19 PLEO flex listings, only TWO state a section. ⭐ This one, and the 10 × 10 top-view version. ⚠ The other seventeen leave it invisible.
• ⚠ And no profile listing names a compatible flex either, ⭐ so on seventeen of the nineteen the pairing cannot be made from the catalogue at all.
• ⭐ It matters because the fit is unforgiving. ⚠ A 6.5 mm flex in a 10 mm channel rattles and sits crooked; ⛔ a 10 mm flex will not enter a 6.5 mm channel at all. ⭐ Tell us the flex and we will confirm the profile.

⭐ 6.5 × 11 mm — taller than it is wide, and what that means

⭐ This section is 6.5 mm across and 11 mm deep. ⭐ Side-emitting flex fires from the EDGE, and on a section this shape the emitting edge is the narrow 6.5 mm face — ⭐ which gives a fine, well-defined line rather than a broad glow. ⭐ That suits signage and outlines, where the line has a drawn shape. ⚠ The 11 mm depth is the dimension that has to fit your channel or reveal, ⭐ and it is the one people measure last.

⭐ 7.2 W — the long-run version, and it publishes its limit

⭐ This is the 7.2 W per metre flex, ⭐ and its 20 m sibling publishes what none of the other wattages does: up to 20 m of continuous light from a single driver feed at one end, or up to 40 m powered from both ends. ⭐ Half the watts per metre of the 14.4 buys roughly twice the reach, because voltage drop is driven by current. ⭐ So for a long signage run or a facade outline, this is the wattage to start from.

✅ What is published

⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works

• ⭐ Signage and outlines — ⭐ a fine, drawn line.
• ⭐ Long runs — ⭐ 7.2 W/m reaches furthest.
• ⭐ In a 6.5 × 11 Pleo profile — ⭐ the stated pairing.
• ⛔ Not in a 10 × 10 channel — ⚠ it will rattle.
• ⛔ Not in a ceiling cove — ⭐ take top view.

Specifying it

Side-emitting 24 V DC LED neon flex, 6.5 × 11 mm, 1 m. 7.2 W per metre. 140 SMD LEDs per metre, cut in 50 mm increments. CRI90. 3000 / 4000 / 5000 K. IP67. Order code PLEO-7.2-S. ⭐⭐ ITS TITLE STATES THE SECTION, AND ONLY TWO OF NINETEEN FLEX LISTINGS DO. That number is the single most useful thing on the page, because it is what pairs a flex to a profile: a 6.5 × 11 mm flex goes in a 6.5 × 11 mm Pleo profile, and that is the whole rule. ⛔ THE OTHER SEVENTEEN LEAVE IT INVISIBLE, and no profile listing names a compatible flex either — so on seventeen of nineteen the pairing cannot be made from the catalogue at all.

Supplied and supported by Lights For You.

Download Datasheet (PDF)
