Domus PLEO-14.4 Neon Side 24V IP67 CRI90 1m

The Domus PLEO-14.4 Neon Side is a 24 V side-emitting LED neon flex — 14.4 W per metre, IP67, sold in 1 m, in RGB.

⭐ Why side-emitting flex exists — and it is geometry, not preference

• ⭐ A strip of flex is a flat ribbon. ⭐ It bends easily in one direction and resists the other — ⭐ exactly like a steel tape measure, which curls along its length but will not bend sideways.
• ⭐ A TOP-VIEW flex emits from its wide face. ⭐ Bending it the easy way keeps the face pointing where you want it — ⭐ which is why it suits a cove, a straight run or a curve in section.
• ⚠ Bending a top-view flex flat on a plane — following a curve drawn on a floor or a wall — means bending the hard way. ⛔ It resists, and it TWISTS: the emitting face rolls over so the light points sideways at the start of the curve and upward at the end. ⭐ The result reads as a fault.
• ⭐ A SIDE-VIEW flex emits from its EDGE. ⭐ So the direction you need it to bend is the easy direction — ⭐ and the emitting edge stays pointing outward all the way round.
• ⭐ THE TEST: draw your run. If the curve is on a flat plane you can walk on or lean against, you need SIDE view. ⭐ If it is straight, or curves like a ribbon standing on edge, TOP view.

⭐ The applications each one is really for

⭐ Signage is the application that makes it obvious. ⭐ Formed lettering and logos are curves drawn on a flat plane — ⭐ which is precisely the case a top-view flex cannot follow. ⭐ Side-emitting flex is what neon-effect signage is made of.

⚠ This listing is RGB, and 1 metre

⭐ Its single option is RGB, and it is sold as a 1 m length rather than a 20 m reel — ⭐ which makes it a sample. ⭐ Buying a metre before a reel lets you test the bend radius on a bench — ⛔ no minimum is published for any PLEO product — ⭐ and see how solid the lit line reads. ⚠ Its title carries CRI90, which is not meaningful on an RGB source.

✅ What is published

⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works

• ⭐ Curves drawn on a flat plane — ⭐ the reason side view exists.
• ⭐ Signage, lettering and logos — ⭐ neon-effect work.
• ⭐ Vertical face washing.
• ⛔ Not in a ceiling cove — ⚠ it fires at the wall behind.
• ⚠ Not as a white sample — ⭐ this one is RGB.

Specifying it

Side-emitting 24 V DC RGB LED neon flex, 1 m. 14.4 W per metre. IP67. Polyurethane enclosure, mounting clips included. ⭐ SIDE VIEW EXISTS FOR A GEOMETRIC REASON, NOT A PREFERENCE. A flex ribbon bends easily one way and resists the other, like a tape measure. ⚠ A TOP-VIEW FLEX BENT FLAT ON A PLANE TWISTS — the emitting face rolls over, pointing sideways at the start of the curve and upward at the end, and the result reads as a fault. ⭐ A SIDE-VIEW FLEX EMITS FROM ITS EDGE, so the direction you need is the easy direction. ⭐ THE TEST: if the curve is drawn on a flat plane, you need side view.

Supplied and supported by Lights For You.

Download Datasheet (PDF)
