Domus Lighting
SKU: 22929

Domus Nova-20 SM 20X10MM 3M C/W Opal Diff & Ec

Colour: Aluminium
$83.95
$83.95
Product Description
Product Description
x

The Domus NOVA-20 SM is a surface-mounted aluminium LED profile — 3 m, with a flat opal PMMA diffuser and end caps, in three finishes, cut to length.

⭐ Every Domus strip profile, compared — because nothing in the catalogue does
Family Nominal Depth ⭐ Choose it for
Micro 8 × 9 mm 9 mm ⭐ The narrowest reveal — ⚠ takes only PLEX-MICRO strip
Corner-16 16 × 16 mm 16 mm ⭐ Corners and 45° reveals
Nova-17 17 × 7 mm 8 mm ⭐ Shallow joinery — ⚠ most prone to dotting
⭐ Nova-20 (this) 20 × 10 mm ≈11 mm ⭐ The all-rounder — 3 m lengths, good blending
Nova-24 24 × 10 mm 11 mm ⭐ Wider strip, more output — ⚠ 2.5 m only
Omega-17 17 × 15 mm 15 mm ⭐ The most even line — ⚠ surface only, tallest
BLOC20 / BLOC-42 ≈19.7 mm sq 19.7 mm ⭐ Square section, deep
CURVE 19.7 × 19.6 mm 19.6 mm ⭐ Round diffuser — a lit tube, not a lit slot
  • ⭐ Two numbers drive the choice, and only one of them is in the name. ⭐ WIDTH decides which strip fits and therefore the output. ⭐ DEPTH decides whether the strip reads as a line or as a row of dots.
  • ⭐ The Nova-20 is the all-rounder of the set: ⭐ enough width for a normal strip, enough depth to blend it, and the 3 m length that means fewer joints than the Nova-24's 2.5 m.
  • ⭐ Take the Omega-17 instead if the run is seen close and evenness matters more than reveal height; ⭐ take the CURVE if you want a lit tube rather than a lit slot.
✅ Surface mounting, and its one requirement

⭐ No routing, no groove, and it retrofits into finished joinery — ⭐ which also means the unpublished width of this range costs you nothing here. ⚠ What it does need is a straight run. ⭐ The clips hold the profile true but cannot straighten a bowed shelf, ⭐ and a wave in the substrate shows in the line of light.

⛔ Not a light fitting

⛔ No strip, no driver. ⭐ Domus IP54 strip range. ⭐ Tell us the run and we will quote all three together.

✅ The specification
Specification Value
Installation ⭐ Surface mounted — no groove
Length ⭐ 3 m — title and order code AGREE
Nominal size 20 × 10 mm — ⛔ no actual dimension published
Diffuser Flat opal PMMA
Material / finish Extruded aluminium — aluminium, black or white
Compatible strip Domus IP54 range — ⛔ not included
⛔ Driver ⛔ Not included
Supplied with End caps
Order code LP-2010-SM-3M
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Long runs with few joints — ⭐ the 3 m length.
  • Retrofit into finished joinery — ⭐ no routing.
  • Under-shelf, pelmet and wardrobe.
  • ⛔ Not on a bowed run.
  • ⛔ Not without a strip and driver.
Specifying it

Surface-mounted LED strip profile, 3 m, nominal 20 × 10 mm. Flat opal PMMA diffuser and end caps. Extruded aluminium in aluminium, black or white. Cut to length. For the Domus IP54 strip range. Order code LP-2010-SM-3M. ⭐ TWO NUMBERS DRIVE A PROFILE CHOICE AND ONLY ONE IS IN THE NAME — width decides which strip fits and therefore the output; DEPTH decides whether the strip reads as a line or a row of dots. ⭐ THE NOVA-20 IS THE ALL-ROUNDER: enough width for a normal strip, enough depth to blend it, and a 3m length that means fewer joints than the Nova-24's 2.5m. ⭐ Take the Omega-17 for the most even line, the CURVE for a lit tube.

Supplied and supported by Lights For You.

Questions
How do I choose between all the Domus profiles?

On two numbers, and only one of them is in the name. Width decides which strip fits and therefore the output. Depth decides whether the strip reads as a continuous line or a row of dots. The families run from the Micro at 8 x 9mm, through the Nova-17, 20 and 24, to the Omega-17 at 15mm deep and the square BLOC and round CURVE profiles at around 19.7mm.

Where does the Nova-20 sit?

It is the all-rounder of the set: enough width for a normal strip, enough depth to blend it, and a 3m length that means fewer joints than the Nova-24's 2.5m. If you have no specific constraint pushing you elsewhere, this is the sensible default of the family.

When would I choose something else?

The Omega-17 if the run is seen close and evenness matters more than reveal height — at 15mm deep it gives the most even line of the family. The Micro if you need the narrowest possible reveal, though it takes only PLEX-MICRO strip. The Corner-16 for corners and 45 degree reveals. And the CURVE if you want a lit tube rather than a lit slot, which is a different look entirely.

Does surface mounting need any preparation?

None — no routing, no groove, and it retrofits into finished joinery. That also means the unpublished width of this range costs you nothing here, since you are not cutting anything to fit it. What it does need is a straight run: the clips hold the profile true but cannot straighten a bowed shelf, and a wave in the substrate shows in the line of light.

Is the 3m length reliable?

Yes. The title says 3m and the order code in its body is LP-2010-SM-3M, so they agree. That is not true everywhere in the Nova family — the Nova-17 recessed listings say 2.5m in the title and carry a 3M code, which is a real conflict.

Does it come with a strip?

No, and no driver. It is complete with the flat opal PMMA diffuser and end caps. It is designed for the Domus IP54 strip range. Tell us the run lengths and we will quote all three parts together so nothing arrives without its partner.

What finish should I choose?

Match the substrate rather than the room. A white profile on a white carcass disappears; an aluminium one on white does not. Under a shelf the profile is seen from below at close range, which is exactly where a mismatch is obvious.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsLP-2010-SM-3M — 22929 Aluminium, 22930 Black, 22931 White
⭐ TWO NUMBERS DRIVE THE CHOICE⚠ And only ONE is in the name
⭐ WIDTH decidesWhich strip fits — ⭐ and therefore the output
⭐ DEPTH decidesWhether the strip reads as a LINE or a row of DOTS
⭐ Micro — 8 × 9mmNarrowest reveal — ⚠ takes only PLEX-MICRO strip
⭐ Nova-17 — 8mm deepShallow joinery — ⚠ most prone to dotting
⭐ NOVA-20 (this) — ≈11mm deep⭐ THE ALL-ROUNDER — ⭐ 3m lengths, good blending
⭐ Nova-24 — 11mm deepWider strip, more output — ⚠ 2.5m only
⭐ Omega-17 — 15mm deepThe MOST EVEN line — ⚠ surface only, tallest
⭐ CURVE — round diffuserA lit TUBE, not a lit slot
✅ Length3m — ⭐ title and order code AGREE
⚠ Surface mounting needsA STRAIGHT run — ⭐ clips hold the profile true, not the shelf

Variant specifications

NeedTake
⭐ A sensible default⭐ Nova-20 — this one
⭐ The most even line⭐ Omega-17 (15mm deep)
⭐ The narrowest revealMicro
⭐ A lit tubeCURVE
