Domus Lighting LED Profiles Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Domus Lighting LED Profiles Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec
Loading... + Add to wishlist - Remove from wishlist
Domus Lighting
SKU: 21969

Domus Nova-17 REC 17X7MM P/M C/W Black Diff & Ec

Colour: Aluminium
$16.95
$16.95
Product Description
Product Description
x

The Domus NOVA-17 REC is a recessed aluminium LED profile, sold per metre — 17 × 7 mm channel, with a black PMMA diffuser and end caps, in three finishes.

⛔⛔ The same profile appears nine times, under two product categories
Listing Category Datasheet?
Nova-17 REC 2.5M — black diffuser LED Profiles ⛔ No
Nova-17 REC 2.5M — opal diffuser LED Profiles ⛔ No
⭐ Nova-17 REC per metre — black (this) LED Profiles ⛔ No
Nova-17 SM 3M — black / opal LED Profiles ⛔ No
Nova-17 SM per metre — black LED Profiles ⛔ No
Nova-17/Omega-17 diffuser only LED Profiles ⛔ No
⭐ NOVA-17 Recessed LED Mounting Profile ⚠ Aluminium Profile ⭐ YES
⭐ NOVA-17 Surface Mounting LED Profile ⚠ Aluminium Profile ⭐ YES
  • ⛔ The last two are the same recessed and surface profiles as the rest, sold under a second product category with different titles and no order code. ⚠ Nothing on any listing points at any other.
  • ⭐ And they are the ONLY two carrying a datasheet — ⭐ which is where the profile dimensions come from: recessed 23 mm wide, surface 17 mm, both 8 mm high.
  • ⭐ So the seven detailed listings lack the one document, and the two that have it lack the detail. ⚠ A buyer needs both pages and has no way to know the other exists.
  • ⭐ This page carries the figures from both.
⭐ The number that decides the joinery: 17 mm or 23 mm?
  • ⭐ Both, and they do different jobs. ⭐ The RECESSED profile is 23 mm across because it has a FLANGE — ⭐ a lip that sits on the surface. ⭐ The SURFACE version of the same profile is 17 mm, because it has no flange to add.
  • ⭐ The flange is genuinely useful: it covers the edge of your groove, ⭐ so a cut that is a millimetre rough disappears under it. ⚠ Without a flange the groove edge is the finished edge, and it has to be clean.
  • ⭐ Confirm the exact routing dimension with us before the joinery is cut — ⚠ the datasheet gives outside dimensions, and the groove needs the body width plus a working tolerance, not the flange width.
⛔ Not a light fitting

⛔ No strip, no driver. ⭐ Designed for the Domus IP54 strip range. ⭐ Tell us the run and we will quote all three parts together.

✅ The specification
Specification Value
Installation Recess mounted, sold per metre
Strip channel 17 × 7 mm
⭐ Profile ⭐ 23 mm across the flange, 8 mm high
Diffuser Flat black PMMA
Material / finish Extruded aluminium — aluminium, black or white
Compatible strip Domus IP54 range — ⛔ not included
⛔ Driver ⛔ Not included
Supplied with End caps
⛔ Datasheet ⛔ Not on this listing — ⭐ on the duplicate under "Aluminium Profile"
⛔ Made to order, cut to length

No lead time is published. Call our team to confirm. ⭐ We will.

Where it works
  • ⭐ Several short runs — ⭐ where metreage beats a stick.
  • Dark ceilings and black reveals — ⭐ the black diffuser.
  • Recessed joinery and plasterboard.
  • ⛔ Not routed until the exact groove width is confirmed.
  • ⛔ Not without a strip and driver.
Specifying it

Recessed LED strip profile, sold per metre. 17 × 7 mm channel, 23 mm across the flange, 8 mm high. Flat black PMMA diffuser and end caps. Extruded aluminium in aluminium, black or white. For the Domus IP54 strip range. Order code LP-1707-RC-B. ⛔ THIS PROFILE APPEARS NINE TIMES ACROSS TWO PRODUCT CATEGORIES, and the only two listings with a DATASHEET are the two that duplicate it under a different category and title — so the detailed listings lack the document, and the documented ones lack the detail. ⭐ THE FLANGE IS THE USEFUL PART: recessed is 23 mm across because it has a lip that covers the edge of your groove; the surface version is 17 mm because it has none.

Supplied and supported by Lights For You.

Questions
Why do I keep finding the same profile under different names?

Because it is sold as nine listings across two product categories. Seven sit under "LED Profiles" with order codes and diffuser and length variants; two sit under "Aluminium Profile" with different titles, no order code, and no length in the name. Nothing on any listing points at any other, so a buyer has no way to know the others exist.

Does it matter which one I buy?

For the product, no — they are the same extrusion. For information, yes: the two under "Aluminium Profile" are the only ones carrying a datasheet, which is where the profile dimensions come from. So the seven detailed listings lack the one document, and the two documented ones lack the detail. This page carries the figures from both.

Is it 17mm or 23mm?

Both, and they do different jobs. The recessed profile is 23mm across because it has a flange — a lip that sits on the surface. The surface version of the same profile is 17mm, because it has no flange to add. The strip channel inside is 17 x 7mm in both cases.

What is the flange for?

It covers the edge of your groove, so a cut that is a millimetre rough disappears under it. That is genuinely useful on site. Without a flange the groove edge is the finished edge and it has to be clean, which is a higher standard than most joinery routing achieves first time.

What width do I actually rout?

Not the flange width. The groove needs the body width plus a working tolerance, and the datasheet gives outside dimensions. Confirm the exact routing dimension with us before the joinery is cut — this is the one number that cannot be corrected afterwards.

Does it come with a strip?

No, and no driver either. It is complete with the black diffuser and end caps. It is designed for the Domus IP54 strip range. Tell us the run lengths and we will quote all three parts together so nothing arrives without its partner.

Why buy per metre rather than a fixed length?

Because it suits several short runs better than a single stick does — you are quoting metreage across a job rather than one continuous piece. Both are cut to order in any case. Tell us the run lengths and we will work out which listing prices your job properly.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsLP-1707-RC-B per metre — 21969 Aluminium, 21970 Black, 21971 White
⛔ NINE LISTINGS FOR ONE PROFILE FAMILYAcross TWO product categories
⚠ Seven under "LED Profiles"With order codes and variants — ⛔ but NO datasheet
⚠ Two under "Aluminium Profile"Different titles, no order code — ⭐ and the ONLY ones with a DATASHEET
⭐ So the detailed listings lack the document⚠ And the documented ones lack the detail
⭐ Nothing on any listingPoints at any other — ⭐ this page carries both
⭐ 17mm OR 23mm? BOTH⭐ Recessed is 23mm because it has a FLANGE; surface is 17mm because it has none
⭐ What the flange doesCovers the edge of your groove — ⭐ a rough cut disappears under it
⚠ What to routThe BODY width plus tolerance — ⛔ NOT the flange width; ⭐ confirm with us
⛔ Strip / driverNeither included — ⭐ for the Domus IP54 range
Channel / height17 × 7mm · 8mm high

Variant specifications

VersionWidthFlange?
⭐ Recessed (this)23mm⭐ Yes — covers the groove edge
Surface17mm⛔ No
Strip channel17 × 7mmBoth
