Domus Lighting
SKU: 15194

DOMUS AVIGNON WALL BRACKET UP S-ARM B22

1 Year Warranty
1 Year Warranty
Color: BEIGE
$371.45
$515.99
$371.45
Product Description
Product Description
x

The Domus AVIGNON wall bracket, up-facing on an S-arm, holds the lantern above the arm against a wall — die-cast aluminium with a moulded acrylic lens, IP43, taking a B22 lamp, in beige, black, burgundy, green or white. 290 mm projection, 500 mm overall height.

⛔ This item is made to order

Domus builds this fitting to order and asks for up to 10 business days for production before it ships. It is not picked off a shelf.

  • ⭐ That is the trade-off for the five finishes. The body is powder-coated in the colour you choose after you order, which is why the range offers Beige, Black, Burgundy, Green and White rather than one stocked colour.
  • ⚠ Plan the lead time into the job. If it is needed for a handover, a settlement or a booked electrician, tell us the date when you order and we will confirm the production window with Domus.
  • ⚠ Order the whole set together. On a property using several of these, a second order placed later starts its own ten days — and a later powder-coat batch is not guaranteed to match the first.

✅ This is the traditional carriage-lamp arrangement — the lantern held up and clear on a curved arm, the way an exterior lantern has been mounted on a wall for two hundred years.

It throws light further out than the down-arm version, because the lantern sits higher and the light has further to fall before it reaches the ground. ✅ That suits a facade, an approach, or a wall seen from a distance, where the fitting reads as an object as much as a light.

⚠ The down-arm version is the better choice where people pass close to the wall — a doorway, a step, a narrow side path — because the lantern sits lower and puts light where they are walking. Both take the same lantern and the same five finishes, so a property can mix them.

Mounting height, and why it matters more on an up-arm
  • 500 mm overall, with a 290 mm projection.
  • ⚠ On an up-arm the lantern is at the top of that 500 mm, so the fixing point sits well below the light. Set the fixing so the lantern is where you want it, not the bracket.
  • ✅ Typically the lantern wants to be at 2.1–2.4 m beside a door — above the head of anyone standing there, below the eave.
  • ⚠ Check the eave. An up-arm needs clearance above it, and a 500 mm fitting under a low soffit will not fit at the height you want.
⛔ The maximum lamp wattage is not recorded anywhere
  • B22 bayonet, and no source states a maximum. ⚠ Every AVIGNON configuration shares this.
  • ✅ An LED B22 at 9–11 W gives roughly what a 60 W incandescent did and runs cool inside a sealed acrylic lens.
  • ✅ On an up-arm a filament globe is more defensible than on the down version, because the lantern is held higher and further from the eyeline — and a visible filament suits the traditional form.
  • 2700–3000 K. Warm light on render, brick and stone reads as light; cooler reads as security.
⚠ IP43 — and an up-arm is slightly more exposed
  • Spray falling at up to 60° from vertical — not driven rain, not hosing.
  • ⚠ The lantern sits higher and further from the wall's shelter than on a down-arm, so on an exposed elevation it catches more. ✅ Under an eave it is well protected.
  • ⚠ The acrylic lens can craze under years of full sun. On a north-facing wall it is in sun most of the day; expect the lens to need replacing before the die-cast body does.
⭐ Seven configurations of one lantern
Configuration Where it goes
Wall bracket, up arm (this) A facade or an approach — lantern held clear
Wall bracket, down arm A doorway, step or path beside the wall
Pillar mount Flat on a pier or wall cap
Post top On an existing post — post not included
Chain pendant Hung from a porch or portico ceiling
1, 2 or 3 heads on a post Six post heights, 1.25 m to 2.4 m

✅ A wall bracket at the door, posts along the path, a pillar mount at the gate — one scheme in three mountings rather than three near-matches. ⚠ No page in the catalogue says the others exist. Tell us the positions and we will quote the set.

⚠ About the "Requires: Wall Bracket" line on its datasheet

Its sheet reads "Requires: Lamp GT-271 Wall Bracket" — ⛔ on a listing that is a wall bracket. The line names another configuration in the family rather than a part. What this needs is a fixing into the wall and a B22 lamp.

Where it works
  • ✅ Facades and approaches, where the fitting is seen from a distance.
  • ✅ Beside a door under an eave, at 2.1–2.4 m to the lantern.
  • ✅ Period and traditional houses — the carriage-lamp form.
  • ⛔ Not an exposed elevation with no overhang — IP43.
  • ⚠ Check the eave clearance above a 500 mm fitting.
  • ⚠ Ask us for the maximum lamp wattage.
Specifying it

AVIGNON traditional exterior wall bracket, up-facing on an S-arm. 290 mm projection, 500 mm overall height. Die-cast aluminium with a moulded acrylic lens; made in Italy, assembled and powder coated in Australia. B22 bayonet lamp holder — lamp not included. 220–240 V AC. IP43 — sheltered positions, not driven rain or hosing. Beige, black, burgundy, green or white. ⚠ Warranty 1 year.

⛔ Maximum lamp wattage is not recorded in any source — ask us. ✅ The same lantern is available in seven configurations, including a down-arm version of this bracket for positions where people pass close to the wall.

Supplied and supported by Lights For You.

Questions
Should I choose the up-arm or the down-arm?

Where the light needs to land, and who sees the fitting. The up-arm holds the lantern above the S-arm — the traditional carriage-lamp arrangement — and throws light further out, which suits a facade, an approach or a wall seen from a distance where the fitting reads as an object. The down-arm hangs it below, putting light lower and closer to the wall, which is better where people pass close by: a doorway, a step, a narrow side path.

At what height should I fix it?

Set the fixing so the lantern is where you want it, not the bracket — on an up-arm the lantern sits at the top of the 500 mm, so the fixing point is well below the light. Beside a door the lantern typically wants to be at 2.1 to 2.4 m: above the head of anyone standing there and below the eave. Check the eave clearance, because an up-arm needs room above it.

How far does it stick out?

290 mm from the wall. That is the same as the down-arm version, so the two are interchangeable in plan — the difference is vertical. On a narrow path or beside a door swing, check it before fixing.

What is the biggest lamp I can put in it?

Not recorded in any source, and every AVIGNON configuration shares that gap. Neither the datasheet nor our record states a maximum for the B22 holder. An LED B22 at 9–11 W sidesteps it — roughly what a 60 W incandescent gave, running cool inside a sealed acrylic lens. Ask us before fitting anything else.

Can I use a filament globe?

On this up-arm version, more defensibly than on the down-arm — the lantern is held higher and further from the eyeline, and a visible filament suits the traditional carriage-lamp form. Keep it warm, 2700 to 3000 K. On the down-arm, where the lantern sits closer to eye level for anyone approaching, opal is the better choice.

Is IP43 enough?

Under an eave, comfortably. On an exposed elevation with no overhang it is marginal — and an up-arm sits higher and further from the wall's shelter than a down-arm, so it catches more. IP43 covers spray falling at up to 60° from vertical, not driven rain and not hosing. Tell us the position and we will say.

Can I match it elsewhere on the property?

Yes — the same lantern head is made in seven configurations: this up-arm bracket, a down-arm bracket, a pillar mount, a post top, a chain pendant, and single, twin or triple head on posts of six heights. A wall bracket at the door, posts along the path and a pillar mount at the gate is one scheme in three mountings. Tell us the positions and we will quote the set.

Product Specifications
Product Specifications
x

Specifications

BrandDomus Lighting
Model / SKUsAVIGNON WALL BRACKET UP — 15194 (Beige) · 15195 (Black) · 15196 (Burgundy) · 15197 (Green) · 15199 (White)
TypeTraditional exterior wall bracket — up-facing on an S-arm
⛔ Made to orderDomus builds this to order — allow up to 10 business days for production before dispatch
Projection290mm
Overall height✅ 500mm — set the fixing so the LANTERN is at the height you want
Lamp BaseB22 bayonet — lamp not included
Maximum lamp wattage⛔ Not recorded in any source — ask us
Recommended lampLED B22, 9–11W, 2700–3000K — a filament is defensible on an up-arm
IP Rating⚠ IP43 — sheltered positions; more exposed than a down-arm
MaterialDie-cast aluminium body, moulded acrylic lens
OriginMade in Italy; assembled and powder coated in Australia
Voltage220–240V AC
FinishesBeige · Black · Burgundy · Green · White
Down-arm version✅ Same lantern, arm below — for doorways and paths beside the wall
Warranty⚠ 1 Year

Variant specifications

The positionArmLantern height
✅ A facade or approach, seen at a distanceUp (this)Top of the 500mm — fix below it
A doorway, step or narrow pathDownLower, closer to the wall
Under a low soffit⚠ Check clearanceAn up-arm needs room above
