Havit Lighting
SKU: HV10921T-BLK

Akril Single Wall Light

3 Years Warranty
3 Years Warranty
IP65 – suitable for outdoors
IP65 – suitable for outdoors
Color Temprature Changing Technology
Color Temprature Changing Technology
Soft ambient light
105 lm Learn More!!
Color: Black
$53.59
$72.95
$53.59
Product Description
Product Description
x

The Akril is a small rectangular wall light — 170 × 65 × 42 mm of poly powder-coated aluminium with a high-grade acrylic lens — that throws light in a single direction, up or down depending on how you mount it. It is the fitting for a run of even, repeated marks along a wall: a front façade, a fence line, a stair flight or a path-side rendered wall, where a wide floodlight would be too much and a bollard would be in the way.

It is a low-voltage fitting, and that is the main decision

The Akril runs on 12 V DC, not on house supply. It needs a 12 V DC LED driver, sized to the total load of every fitting on the run, and Havit sells a range of them for exactly this. Do not connect it directly to 240 V — the LED will be destroyed and the warranty voided. The upside is what low voltage buys you outdoors: it is Protection Class 3, so no earth is required at the fitting, and the cabling itself is far less hazardous in a garden bed than a house-voltage run.

Output

A built-in 3 W LED gives 105–115 lm. That is an accent figure, not a floodlight figure, and it is the correct amount for the job: a wall grazed by a soft band of light at 3 m spacings reads as designed, while the same wall hit by four times the output reads as a security light. Plan on several of these rather than one.

Colour temperature

Tri-colour and switch-selected at installation: 3000K, 4000K or 5500K. 4000K is the brightest at 115 lm, 5500K gives 110 lm and 3000K gives 105 lm. Set every fitting in a run to the same setting before they go up — mixed colour temperatures along one wall are the single most visible mistake in exterior lighting, and SDCM <5 only guarantees consistency between fittings set the same way.

Rating and limits

It is IP65, so it is rated against dust and water jets from any direction — suitable for an exposed wall, not for immersion. Impact rating is IK04 and glare is quoted at UGR <35, with CRI >80 and a lamp expectancy of >30,000 hrs. One thing to plan around: Havit specifies this model as not dimmable, so it should be switched rather than wired to a dimmer. It comes in black or white, both at the same price, with a 3 years replacement warranty. Lights For You also lists the two-light version of the same body, which throws up and down from one point.

Questions
Can I wire it straight to the house supply?

No. It is a 12 V DC fitting and needs a 12 V DC LED driver between the supply and the light. Havit lists a full range of drivers for this. Connecting it directly to house voltage will destroy the LED and void the warranty.

What size driver do I need?

Add up the load of every fitting on the run — each Akril single is 3 W — and choose a driver comfortably above that total, leaving headroom rather than running it at its limit. Cable run length also matters at low voltage; your electrician will size the cable to avoid a voltage drop at the far end.

Does it need an earth?

No. It is Protection Class 3, which is the safety class for separated extra-low-voltage equipment, so no earth is required at the fitting itself.

Can it be dimmed?

No. Havit specifies this model as non-dimmable. Switch it rather than wiring it to a dimmer — a dimmer on the low-voltage side of the driver will not work correctly and may damage the driver.

Is it OK in an exposed position outdoors?

Yes. It is IP65, which covers dust and water jets from any direction, so a wall with no shelter is within the rating. It is not rated for immersion or for being buried.

Which colour setting gives the most light?

4000K, at 115 lm. 5500K gives 110 lm and 3000K gives 105 lm. The differences are small, so choose on appearance — but set every fitting in a run identically, because a mismatched setting along one wall is obvious.

How far apart should I space them?

There is no single answer, but around 2.5–3 m is a common spacing for a 105–115 lm accent on a wall. Closer together gives a continuous scalloped band; further apart gives distinct pools with dark gaps between.

Product Specifications
Product Specifications
x

Specifications

RangeAkril
TypeWall light — single direction
MaterialAluminium, poly powder coated
FinishBlack or white
DiffuserAcrylic lens
Installation typeWall — surface mounted
Lamp baseBuilt-in LED
Power3 W
Colour temperatureTri colour — 3000K, 4000K, 5500K (switch-selected at installation)
Lumen output105 lm / 115 lm / 110 lm (3000K / 4000K / 5500K)
CRI>80
SDCM<5
UGR<35
IP ratingIP65
IK ratingIK04
Input voltage12 V DC — requires a 12 V DC LED driver
Protection classClass 3 (no earth required)
DimmableNo
Lamp expectancy>30,000 hrs
Dimensions170 × 65 × 42 mm
Warranty3 Years Replacement*

Variant specifications

Part numberFinishColour temperatureLumensPowerSupplyBarcode
HV10921T-BLKBlack3000K / 4000K / 5500K105lm / 115lm / 110lm3 W12 V DC — 12 V DC LED driver required9350418041678
HV10921T-WHTWhite3000K / 4000K / 5500K105lm / 115lm / 110lm3 W12 V DC — 12 V DC LED driver required9350418041685
Data Sheet & Manual
Data Sheet & Manual
x

This browser does not support PDFs. Please download the PDF to view it: Download PDF.

Download Datasheet (PDF)
