xThe 703 is a gimble downlight frame — frame only. It is adjustable, takes a 90 mm cut-out, and contains no light source.
There is no LED in this product. It is the trim and the tilting mechanism; the light comes from a twist-on LED module bought separately. Tell us what you are lighting and we will match the module — wattage, colour temperature and beam angle are all decided by that choice, not by this frame. (Our record lists “12 W” against it, which is meaningless on an empty frame.)
Gimble means it tilts
A fixed downlight points straight down and lights the floor. A gimble frame swivels within its housing, so you can aim the beam at a painting, a joinery run, a feature wall or a bench. That single degree of freedom is the difference between general lighting and lighting something on purpose.
Why buy a frame separately at all
Two real advantages. First, you choose the module — and can change it later for a different wattage or colour without touching the ceiling. Second, when a module eventually fails, you twist in a new one rather than cutting an integrated downlight out of the plasterboard.
105 mm trim into a 90 mm hole
15 mm of cover around the cut edge, which is the standard Australian downlight hole — so it drops into most existing ceilings without new cutting.
IP44 and IC-4
IP44 means it is rated for splashing water, so it can go in a bathroom or laundry. IC-4 means insulation may be laid directly over it, with no clearance gap to cut. Both ratings apply to the frame; confirm the module carries them too.
Warranty is one year. Our datasheet says five and the product record says one. We publish the shorter and will confirm with Telbix on request — a fivefold difference is worth settling before you buy in quantity.
Where it works
- Accenting artwork, joinery and feature walls.
- Bathrooms and laundries — IP44.
- Insulated ceilings — IC-4.
- Retrofits into an existing 90 mm hole.
Specifying it
ø105 mm trim, 90 mm cut-out, white, adjustable gimble. No LED module included — twist-on modules sold separately. IP44 — bathrooms YES, IC-4 — insulation may cover it. Installation by a licensed electrician. Warranty published as one year — the sheet says five; ask us.
Supplied and supported by Lights For You.
Questions
Does it come with an LED?
No — it is the frame and tilting mechanism only. The light comes from a twist-on module bought separately. Tell us what you are lighting and we will match one.
What wattage is it?
The frame has no wattage. Our record lists 12 W against it, which is meaningless on an empty frame — wattage is decided by the module you choose.
What does gimble mean?
It swivels within its housing, so you can aim the beam at a painting, a joinery run or a bench instead of straight down at the floor.
Why buy a frame and module separately?
You choose the module and can change it later for a different wattage or colour without touching the ceiling — and when one fails you twist in a new one rather than cutting an integrated downlight out of the plasterboard.
What size hole does it need?
90 mm — the standard Australian downlight cut-out — with a 105 mm trim, so 15 mm of cover around the cut edge.
Can it go in a bathroom or under insulation?
The frame is IP44 and IC-4, so yes to both — but confirm the module you pair with it carries the same ratings.
What is the warranty?
We publish one year. The datasheet says five and the record says one — a fivefold difference. Ask us and we will settle it with Telbix before you buy in quantity.
Product Specifications
xSpecifications
| Brand | Telbix Lighting |
|---|---|
| Model / SKU | MDL-703-WH |
| Type | Downlight gimble frame — FRAME ONLY, no LED |
| Finishes | White |
| Light source | NOT INCLUDED — twist-on LED module sold separately |
| Adjustment | Gimble — tilts to aim the beam |
| IP Rating | IP44 — bathrooms YES |
| Insulation Rating | IC-4 — insulation may cover the fitting |
| Trim Diameter | ø105mm |
| Cut-out | 90mm — standard Australian hole |
| Warranty | 1 Year published — the sheet says 5 Years; ask us |
Variant specifications
| Order code | Finish | Trim | Cut-out | LED module | Adjustment |
|---|---|---|---|---|---|
| MDL-703-WH | White | ø105mm | 90mm | Sold separately | Gimble / tilt |
