313m³/h Ventair Standard Through Wall

313m³/h Ventair Standard Through WallDescription:

150mm Standard Through Wall Fan Kit - Auto Shutter.

Ventair 313m³/h Standard Through Wall Exhaust Fan – Reliable Wall-Mount Ventilation

313m³/h Ventair Standard Through Wall offers powerful and quiet ventilation, designed to extract stale air and moisture from bathrooms, kitchens, laundries, and other enclosed spaces. With a strong 313m³/h airflow capacity, this fan ensures cleaner, fresher air in residential and light commercial settings.

Key Features

• Powerful Ventilation
  Efficiently removes steam, smoke, and odors with a strong 313 cubic metres per hour airflow output.

• Wall-Mounted Design
  Specifically engineered for through-wall installation, ideal for spaces where ceiling or window mounting isn’t practical.

• Quiet Operation
  Operates with minimal noise, making it suitable for both domestic and commercial use.

• Durable Construction
  Built from UV-stabilised ABS plastic, ensuring longevity and resistance to moisture and discoloration.

• Easy Installation
  Comes with a wall tube and grille kit for hassle-free setup through brick or timber walls.

• Low Power Consumption
  Energy-efficient motor keeps running costs low while delivering consistent performance.

Features:

• Electrically operated louvre shutters open automatically when fan is running - prevents back-draughts.
• Includes weatherproof cowl
• Standard series operated from remote switch (not included)
• The unique low profile design enables these fans to be installed unobtrusively into any wall (requires a minimum wall cavity of 110mm)
• These axial fans have been upgraded with ball bearing motors to prolong the life of the motor
• 5 year warranty

Specifications:

• Colour: White
• Exhaust Motor Power: 25w
• Air Delivery: 313m³h (87L/sec)
• Grille Size: 200mm x 200mm
• Cut out size: Ø160mm
• Duct outlet size: Ø150mm
• Noise Level: 40dB(A)
• IP Rating: IPX4
• Warranty: 5 years
• Power Input: 220-240V~50Hz
• Installation: Qualified Electrician Required
• Ducting Length: 375mm

Order Code:

• FAN0136
• Brand: Ventair
  Sku(s): FAN0136
  Product Type: Exhaust Fan
  Colour: White
  Grille Size: 200mm x 200mm
  Cut: Out: Size: Ø160mm
  Duct outlet Size: Ø150mm
  Ducting Length: 375mm
  Noise Level: 40dB(A)
  Extraction: 313m³h
  Motor Wattage: 25w
  Voltage: 220: 240v
  IP Rating: IPX4
  Warranty: 5 Years
