DOMUS CHESTER WALL BRACKET C-ARM

The Domus CHESTER wall bracket, curved arm facing down, holds the CHESTER lantern below a curved arm — 305 mm wide × 422 mm high × 370 mm projection, die-cast aluminium with a moulded acrylic lens, IP43, taking one B22 lamp.

⛔ This item is made to order

Domus builds this fitting to order and asks for up to 10 business days for production before it ships. It is not picked off a shelf.

• ⭐ That is the trade-off for the finish choice. The body is powder-coated in the colour you pick after you order, which is why the range offers five rather than one stocked colour.
• ⚠ Plan the lead time into the job. If it is needed for a handover, a settlement or a booked electrician, tell us the date when you order and we will confirm the production window with Domus.
• ⚠ Order the whole set together. On a property using several of these, a second order placed later starts its own ten days — and a later powder-coat batch is not guaranteed to match the first.

⛔ Its title does not say which way it faces, and its sibling’s does

• ⛔ Only its web address gives it away — it reads chester-wall-bracket-down-c-arm-b22.
• ⚠ Two brackets, one titled and one not, is the sort of thing that produces the wrong delivery — and up versus down is the whole choice on a wall bracket.
• ✅ This is the DOWN-facing curved-arm bracket. That is what you will receive.

⭐ Choosing between the four CHESTER wall brackets

• ⭐ The straight arms are 510 mm tall and the curved arms 422 mm — so the curve is the more compact choice as well as the softer one.
• ⭐ Down-facing puts the lantern lower and closer to what you are lighting — a door, a step, a path. Up-facing throws more light onto the wall above and reads more formal.
• ⚠ This one projects 370 mm, the deepest of the four that record a projection. Check it against a doorway or a passing point.
• ✅ This listing records all three dimensions, which two of the four do not.

⛔ A B22 holder with no maximum wattage

• One B22 lamp, not included, no maximum recorded anywhere in the family.
• ✅ B22 LED at 9–11 W, warm, enclosed and damp rated.
• ⭐ On a down-facing bracket beside a door the lantern is at eye level, so a warm modest lamp matters more than on a post.

⭐ There is a replacement lens for it

The “Requires: Lamp GT-131…” line on its datasheet is the CHESTER series code — a GTA-131 replacement acrylic panel set is sold separately. ⭐ The acrylic is what fails on these lanterns; the cast body lasts decades. ✅ Nothing extra is required to install it.

Where it works

• Beside a front door or a garage door, lighting the approach.
• Along a path or a boundary wall, repeated.
• Matched with CHESTER posts and pillar mounts across a property.
• ⚠ Check the 370 mm projection at a doorway or a narrow passage.
• ⚠ IP43 — not a wash-down or coastal front-line position.

Specifying it

Wall bracket, curved arm, lantern facing DOWN. Die-cast aluminium with a moulded acrylic lens. IP43. 220–240 V AC. One B22 lamp — not included. 305 mm wide × 422 mm high × 370 mm projection. Made in Italy, assembled and powder-coated in Australia. Beige, Black, Burgundy, Green or White. ⚠ Warranty 1 year. ⛔ The listing title does not state the direction — this is the DOWN-facing version; its up-facing sibling is titled "UP C-ARM". ⛔ No maximum lamp wattage recorded. ⭐ A GTA-131 replacement acrylic panel set is sold separately.

Supplied and supported by Lights For You.

Download Datasheet (PDF)
