Mini Recessed LED Downlights by Havit – HV5701T Square & HV5702T Round
13 Aug 2025
Havit HV5701T & HV5702T – Square & Round Mini Recessed LED Downlights
Compact 38mm downlights • IP54 front • TRI Colour • CRI ≥90 • Triac dimmable • Built-in 3W LED
The Havit HV5701T (Square) and HV5702T (Round) Mini Recessed LED Downlights are compact, fixed fittings designed for precision lighting in kitchens, bathrooms, joinery, and display applications. At just 46mm across with a 38mm cut-out, these downlights deliver high-quality, energy-efficient light from a discreet form factor.
Why choose the HV5701T & HV5702T range?
- Space-saving design – Perfect for cabinetry, niches, and tight ceiling spaces.
- High CRI ≥90 – Produces vibrant, accurate colours.
- TRI Colour flexibility – Select 3000K, 4000K, or 5500K to match your space.
- Triac dimmable – Adjust brightness for task or mood lighting.
- Durable aluminium construction – Powder-coated Black or White finish.
- Moisture resistant – IP54 front makes them suitable for damp zones.
HV5702T – Round
- HV5702T-BLK – Black finish
- HV5702T-WHT – White finish
- Lumen output: 240–270lm depending on CCT
HV5701T – Square
- HV5701T-BLK – Black finish
- HV5701T-WHT – White finish
- Lumen output: 240–270lm depending on CCT
Specifications (Both Models)
| Brand | Havit Lighting |
|---|---|
| Shape | HV5701T – Square / HV5702T – Round |
| Material | Aluminium |
| Finishes | Black or White powder-coated |
| IP Rating | IP54 (Front only) |
| Beam Angle | 45° |
| CRI | ≥90 |
| Input Voltage | 240V AC |
| Wattage | 3W (Built-in LED) |
| Lumen Output | 3000K: 240lm / 4000K: 265lm / 5500K: 270lm |
| Dimmable | Yes – Triac |
| Driver | Supplied with IP20 LED driver (flex & plug) |
| Cut-Out | Ø38mm |
| Dimensions | Round: Ø46 × 41mm / Square: 46×46 × 41mm |
| Warranty | 3-Year replacement |
Ideal applications
Kitchens
Task and under-cabinet lighting with high CRI for accurate colour.
Task and under-cabinet lighting with high CRI for accurate colour.
Bathrooms
Moisture-resistant IP54 front for damp zones.
Moisture-resistant IP54 front for damp zones.
Display areas
Perfect for retail shelves, art displays, and niches.
Perfect for retail shelves, art displays, and niches.
Hallways & staircases
Compact accent lighting with adjustable brightness.
Compact accent lighting with adjustable brightness.
Choose your perfect shape – round or square
Both the HV5701T Square and HV5702T Round deliver exceptional performance in a compact form. Pick the profile that fits your design and enjoy years of reliable, high-quality light.
