Havit HV3206 Mini Recessed Step Light – IP67, TRI Colour & Dimmable
HV3206T Mini Recessed LED Step Light (Havit): Small Size, Big Impact
IP67 weatherproof • TRI Colour (3000K/4000K/5500K) • Triac dimmable • 12V DC • Built-in 1W LED
Add safe, stylish wayfinding to stairs, decks and pathways with the Havit HV3206 Mini Recessed Round Step Light . This compact, low-glare luminaire delivers precise accent lighting with premium weather protection and flexible colour temperature control.
Why choose the HV3206 for steps, decks & paths?
- Discreet recessed design — Ø55 mm face and 27 mm height for a flush, modern look.
- Built for outdoors — IP67 rating keeps dust and water out for long-term reliability.
- TRI Colour — Select 3000K / 4000K / 5500K to match ambience and application.
- Triac dimmable — Dial brightness for safety or mood lighting.
- Energy-efficient — Built-in 1W LED delivers up to 50 lumens where you need it.
- Finish options — Antique Brass, Brass, Black, White or Stainless Steel to suit any palette.
Best-fit applications
Improve safety with subtle, low-glare path lighting.
Define perimeters and reduce trip hazards.
Guide guests through gardens and courtyards.
Great for hall steps and cinema room aisles.
Key specifications
| Brand | Havit Lighting |
|---|---|
| Model / SKUs | HV3206T-AB-12V, HV3206T-BR-12V, HV3206T-BLK-12V, HV3206T-WHT-12V, HV3206T-SS316-12V |
| Type | Mini recessed round LED step light |
| Finishes | Antique Brass, Brass, Black, White, Stainless Steel |
| Material | Aluminium (SS316 face for Stainless Steel version) |
| Input Voltage | 12V DC (requires suitable LED driver) |
| Wattage | 1W (built-in LED) |
| Dimming | Triac dimmable |
| Colour Temp | TRI Colour: 3000K / 4000K / 5500K |
| Lumen Output | 40 lm (3000K) / 50 lm (4000K) / 45 lm (5500K) |
| CRI | >80 |
| IP Rating | IP67 |
| Dimensions | Diameter Ø55 mm × Height 27 mm |
| Cut-Out | Ø43 mm (without canister) / Ø50 mm (with canister) |
| Warranty | 3-Year replacement |
Installation notes
- Plan cut-outs: Ø43 mm (no canister) or Ø50 mm (with canister).
- Space fittings to avoid glare and ensure even step illumination.
- Use Triac-compatible dimming gear if dimming is required.
Ready to light the way?
Choose your finish and colour temperature on the product page, then pair with a compatible 12V driver for a complete, long-life solution.
FAQs
Can I change the colour temperature after installation?
Yes. The HV3206 is TRI Colour, allowing you to select 3000K, 4000K or 5500K during setup.
Is the light suitable for coastal environments?
For coastal areas, the Stainless Steel (SS316) variant offers enhanced corrosion resistance.
Do I need a separate transformer?
Yes. The HV3206 runs on 12V DC and must be paired with a suitable LED driver (transformer) — sold separately.
Is it dimmable?
Yes, it supports Triac dimming when paired with compatible dimming gear.
